Engine: |
4-stroke, 2-cylinder,
OHV, 90° V Liquid-cooled |
Displacement: |
783cc |
Starting system: |
Electric |
Bore x stroke: |
85 x 69mm |
Compression ratio: |
10.7:1 |
Fuel system: |
DFI® with two
36mm Mikuni throttle bodies
|
Ignition: |
TCBI with electronic
advance |
Transmission: |
Continuously
variable belt-drive transmission
with high and low range, reverse,
and a wet centrifugal clutch |
Final drive: |
Selectable 4-wheel
drive with locking front differential,
shaf |
Frame: |
Steel
Tube Double-X Reinforcement |
Front suspension
/ wheel travel: |
Color-matched
dual A-Arms with piggyback reservoir
coil-over FOX Podium shocks,
with adjustable spring preload
and 24-way compression damping
8” |
Rear suspension
/ wheel travel: |
Color-matched
Independent Rear Suspension
(IRS) with new piggyback reservoir
coil-over FOX Podium shocks,
with adjustable spring preload
and 24-way compression damping
/ 8.3” |
Front tires:
|
Maxxis® 26x9-12 |
Rear tires: |
Maxxis® 26x11-12 |
Front brakes: |
Dual hydraulic
discs with two-piston calipers
|
Rear brake: |
Sealed, oil-bathed,
multi-disc |
Overall length: |
118.1 in |
Overall width: |
61.6” |
Overall height: |
75.8 in |
Wheelbase: |
85.8” |
Ground clearance: |
11.2” |
Lighting: |
(2) 35W headlights,
(2) 8W taillights, 24W stoplight |
Cargo bed capacity: |
600 lb, 43.3
W x 27.6 L x 10.4” H |
Load capacity: |
1,109 lb |
Towing capacity: |
1,300 lb |
Curb weight: |
1,560.4 lb** |
Fuel capacity: |
7.9 gallons |
Instruments: |
Multi-function
digital meter with speedometer,
fuel gauge, clock, hour meter,
odometer, dual trip meter and
parking-brake indicator, R/N/P/4WD,
water temp and low-oil-pressure
indicators |
Colors: |
Bright White |
Warranty: |
Kawasaki Strong
3 Year Limited Warranty |
Good Times™ Protection
Plan (optional): |
12, 24, 36 months |
