ENGINE |
|
| Type |
976 cc V-twin, liquid-cooled, SOHC, 8-valve (4-valve / cyl) |
| Bore
& Stroke |
91 x 75 mm |
| Fuel
Delivery |
46 mm Throttle Body, 2 Siemens† VDO injectors |
| Starting
System |
Electric |
| Transmission |
CVT, sub-transmission with high, low, park, neutral & reverse. Standard engine braking |
| Drive
Train |
Selectable 2WD / 4WD shaft driven with Visco-Lok‡ auto-locking front differential |
| CHASSIS |
Frame
|
SST G2 6x6 |
| Front
Suspension Type |
Double A-arm |
| Front
Travel |
9 in. |
| Rear
Suspension Type |
Double Torsional Trailing arm Independent (TTI2) |
| Rear
Travel |
9.3 in. |
| Front
Brake |
Dual 214 mm ventilated disc brake with hydraulic
twin-piston calipers |
| Rear
Brake |
Dual 214 mm ventilated disc brake with hydraulic
twin-piston calipers |
| Tires
/Front |
Carlisle† ACT Radial 26 x 8 x 12 in. |
| Tires
/Rear |
Carlisle ACT Radial 26 x 10 x 12 in. |
| Wheels |
Cast-aluminum |
| DIMENSIONS |
| Dry
Weight |
1,135 lb |
| L
x W x H |
122.8 x 48.8 x 49.5 in. |
Wheelbase
|
82 in. |
Seat
Height
|
34.5 in. |
| Ground
Clearance |
11 in. |
| Towing
Capacity |
1,650 lb |
| Rack
Capacity |
Front: 100 lb |
| Rear
Storage |
2.9 gal |
| Fuel
Capacity |
5.4 gal |
| FEATURES |
| Instrumentation |
Multifunction digital LCD gauge: Speedometer, tachometer (bar graph RPM, bottom bar numerical RPM), odometer, trip & hour meters, diagnostic center, gear position, engine hour meter,
6 x 6 indicator, temperature and engine lights, fuel gauge, clock, auto shut off |
| Anti-theft System |
Digitally Encoded Security System (D.E.S.S.™ ) |
| Electrical |
Prewired for
winch |
| Lighting |
230-W from twin 60-W projectors and dual 55-W reflectors with tail light / brake light |
| DC
Outlet |
Lighter type in console, standard connector in the back (15-A) |
| WARRANTY |
| Factory |
5 Year Warranty |
| Extended |
(6 months limited
warranty + 54 month B.E.S.T. extended warranty*) |
