| Engine |
Four-stroke,
liquid-cooled, three-cylinder,
overhead valve diesel |
|
| |
| |
| |
| Air
filter |
Snorkel-type
with cyclone-type two-stage dry
replaceable element |
|
| Oil
filter |
Automotive-type
spin-on canister |
|
| Ignition |
Compression
with glow plugs for starting |
|
| Electrical |
12V
DC, 52 amp-hour battery, 40 amp
alternator |
|
| Transmission |
Kawasaki
Automatic Power-Drive System (KAPS),
with reverse, dual range, 2WD/4WD |
|
| Final
drive |
Shaft,
selectable four-wheel drive with
dual-mode rear differential |
|
| Exhaust |
Muffler
with USFS-approved spark arrestor |
|
| |
| Front
suspension / wheel travel |
Independent,
MacPherson strut / 3.9 in. |
|
| Rear
suspension / wheel travel |
Semi-independent,
De Dion axle with leaf springs
and shocks / 2.8 in. |
|
| Steering |
Electric
power steering assisted rack-and-pinion |
|
| Brakes |
Four-wheel
hydraulic drums, sealed |
|
| |
| |
| |
| |
| |
| |
| |
| Roll
over protective structure (ROPS) |
This
structure meets ROPS requirements
for wheeled tractors under SAE
J1194, 7.1.1, 7.1.2, and 7.5.
This structure also meets FMVSS
216 Roof Crush resistance requirement |
|
| Cargo
bed dimensions (LxWxH) |
46.3
x 51.6 x 11.3 in. / 15.6 cu. ft. |
|
| |
| Cargo
bed capacity |
1,100
lbs. |
|
| Towing
capacity |
1,200
lbs. |
|
| |
| Top
speed |
25
mph, governed |
|
| Instruments |
Parking
brake warning light, coolant temperature
warning light, horn, 12V DC outlet,
(2) 5/21-watt taillight/brake
light, (2) 35-watt sealed-beam
headlight, speedometer |
|
| Color
choices |
Woodsman
Green or Dark Royal Red |
|
| Good
Times™ Protection Plan |
12
or 24 months |
|
| |
