CVT,
sub-transmission with high,
low, park, neutral & reverse,
Standard Engine braking
Drive
Train
Selectable
2w/4w shaft driven with Visco-lok†
front differential
CHASSIS
Frame
SST
G2
SST
Front
Suspension Type
Double
A-arm
Travel
9
in (229 mm)
8
in (203 mm)
Rear
Suspension Type
TTI
independent
Travel
9.3
in (236 mm)
9
in (229 mm)
Front
Brake
Dual
214mm Ventilated discs with
hydraulic twin-piston calipers
Rear
Brake
Single
214mm Ventilated discs with
hydraulic twin-piston calipers
Tires
/Front
26
x 8 x 12 in (660 x 203 x 305
mm)
Tires
/Rear
26
x 10 x 12 in (660 x 254 x 305
mm)
Wheels
12"
cast-aluminum wheels
DIMENSIONS
L
x W x H
86
x 46 x 45 in
(2,184 x 1,168 x 1,143 mm )
94
x 46 x 45 in
(2,387 x 1,168 x 1,143 mm)
Wheelbase
51
in (1,295 mm)
59
in (1,499 mm)
Dry
Weight
729
lbs (331 kg)
719
lbs (326 kg)
Ground
Clearance
12
in (305 mm)
12
in (305 mm)
Seat
Height
34.5
in (877 mm)
34.5
in (877 mm)
Rack
Capacity
Front:
100 lbs (45 kg)
Rear: 200 lbs (90 kg)
Front:
100 lbs (45 kg)
Rear: 200 lbs (90 kg)
Towing
Capacity
1,300
lbs (590 kg)
1,300
lbs (590 kg)
Fuel
Capacity
5.4
US gal (20.5L)
4.3
US gal (16.3L)
Rear
Storage
5.7
US gal (21.4L)
Rear
storage 5.3 US gal (20L)
CRS (Convertible Rack System)
FEATURES
Instrumentation
Multi-function digital LCD gauge:
Speedometer, tachometer (bar
graph RPM, bottom bar numerical
RPM), odometer, trip & hour
meters, diagnostic center, gear
position, engine hour meter,
4x4 indicator, temperature and
engine lights, fuel gauge, auto
shut off after 15 minutes
Anti-theft
D.E.S.S.
(digital encoded security system)
Electrical
Prewired
for winch
Lighting
230-watt
from twin 60-watt projectors
and dual 55-watt reflectors
with tail light/brake light
DC
Outlet
Lighter-type
in console, Standard connector
at the back (15A)
Standard
Colors
Viper Red
Price:
$9,549
X MR- $13,149
Front and rear Air
Control Suspension (ACS)
30-inch (76.2 cm)
Gorilla Axle Silverback tires
14-inch (35.6 cm)
ITP cast-aluminum wheels
Tri-mode dynamic power
steering (DPS)
Integrated snorkel
system (ISS)
Relocated radiator
Visco-Lok QE
3000 lbs winch
Aluminum taper-profile
handlebar
Mudguards
Mud-riding footrests
Outlander MAX platform
X MR-package coloration,
graphics and seat cover
Yellow & Black
w/ X Package Graphics
XT™
PACKAGE
$13,149
Yellow
Black
$11,449
Camo
Pure Magnesium
Tri-mode Dynamic Power
Steering (DPS)
Visco-Lok QE
12" cast-aluminum
wheels
650-watt magneto
WARN 3000lb winch
with roller fairlead and wired
remote control
Aggressive Carlisle
ACT radial tires
Heavy-duty front
& rear bumpers
Handlebar wind deflectors
Colors: Black, Yellow,
Pure Magnesium Metallic, &
Camo
