| Type |
686cc liquid-cooled w/fan, 4-stroke; SOHC, 4
valves |
|
| Bore
x Stroke |
102.0mm x 84.0mm |
|
| Compression
Ratio |
10.0:1
|
|
| Carburetion |
Yamaha
Fuel Injection (YFI) , 41mm |
|
| Ignition |
TCI: Transistor Controlled Ignition |
|
| Starting
System |
Electric |
|
| Transmission |
5-speed w/reverse; wet multiplate clutch |
|
| Drive
Train |
2WD; sealed O-ring chain, eccentric adjustment |
|
|
|
|
| Suspension/Front |
Independent double wishbone w/piggyback High-
/Lo-speed compression, rebound and threaded
preload adjustment, 9.1-in travel |
|
| Suspension/Rear |
Cast aluminum swing arm w/rebound, High-/Lospeed
compression and threaded preload
adjustment, 10.1-in travel |
|
| Brakes/Front |
Dual ventilated hydraulic disc, twin piston |
|
| Brakes/Rear |
Ventilated hydraulic disc, twin piston |
|
| Tires/Front |
Maxxis AT22 x 7-10 |
|
| Tires/Rear |
Maxxis AT20 x 10-9 |
| |
|
| L
x W x H |
72.6 x 45.5 x 43.9 in |
|
| Wheelbase |
50.4 in |
|
| Turning
Radius |
N/A |
|
| Ground
Clearance |
9.5 in |
|
| Fuel
Capacity |
2.9 gal |
|
| Dry
Weight |
422 lb |
|
|
| |
|
|
|
| Lighting |
Dual 30W Krypton multireflector headlights &
3.9/0.5W LED brakelight |
| Colors |
Black/White |
|
|
|
