| Engine Type |
4-Stroke DOHC Single Cylinder |
| Displacement |
952cc |
| Fuel System |
Electronic Fuel Injection |
| Cooling |
Liquid |
| Transmission/Final Drive |
Automatic PVT P/R/N/L/H; Shaft |
| Drive System |
Close Ratio On-Demand True AWD/2WD |
Engine Braking System/
Active Decent Control |
Standard / Standard |
| Front Suspension |
Dual A-Arm 9" (22.9 cm) Travel |
| Rear Suspension |
Dual A-Arm, Rolled 10.25" (26 cm) Travel |
| Front/Rear Brakes |
Single Lever 4-Wheel Hydraulic Disc
with Hydraulic Rear Foot Brake |
| Parking Brake |
Park in Trans./Lockable Hand Lever |
| Front Tires |
26 x 8-14; PXT 6 Ply Radial |
| Rear Tires |
26 x 11-14; PXT 6 Ply Radial |
| Wheels |
Cast Aluminum |
| Wheelbase |
57" (144.8 cm) |
| Estimated Dry Weight |
839 lb (381 kg) |
| Overall Vehicle Size |
86.5 x 47.6 x 58.25" (219.7 x 120.9 x 147.9 cm) |
| Ground Clearance |
11.25" (28.5 cm) |
| Fuel Capacity |
5.25 gal (19.9 L) |
Bed Box (Rack) Dimension / Capacity
|
120 lb (55 kg) / 240 lb (110 kg) |
| Payload Capacity / Towing Capacity |
575 lbs (261 kg) / 1,500 lb (680.4 kg) |
| Cargo System |
Lock & Ride |
| Lighting |
Triple 50w High Beam, Dual 50w Low
Beam Headlights; Dual Brakelights/ Taillights |
| Electronic Power Steering |
Standard |
| Instrumentation |
Digital Gauge, Speedometer, Odometer, Tachometer, Two Tripmeters, Hour Meter, Clock, Service Time, Diagnostic Indicator, Gear Indicator, Fuel Gauge, Hi-Temp/ Low-Batt Lights, DC Outlet |
| Colors |
Bronze Mist |
|
|
