| Engine Type |
4-Stroke DOHC Single Cylinder |
| Displacement |
567cc |
| Fuel System |
Electronic Fuel Injection |
| Cooling |
Liquid |
| Transmission/Final Drive |
Automatic PVT P/R/N/L/H; Shaft |
| Drive System |
On-Demand True
AWD/2WD |
Engine Braking System/
Active Decent Control |
No / No / EPS: Standard / No |
| Front Suspension |
Dual A-arm 8.2" (20.8 cm) Travel |
| Rear Suspension |
Dual A-Arm, IRS 9.5" (24.1 cm) Travel |
| Front/Rear Brakes |
Single Lever 4-Wheel Hydraulic Disc
with Hydraulic Rear Foot Brake |
| Parking Brake |
Park in Trans./Lockable Hand Lever |
| Front Tires |
25 x 8-12; 489 |
| Rear Tires |
25 x 10-12; 489 |
| Wheels |
Stamped Steel |
| Wheelbase |
56" (142.2 cm) |
| Estimated Dry Weight |
728 lb (330 kg) / EPS: 739 lb (336 kg) |
| Overall Vehicle Size |
86 x 48 x 48" (218.4 x 121.9 x 121.9 cm) |
| Ground Clearance |
11" (27.9 cm) |
| Fuel Capacity |
4.5 gal (17 L) |
Bed Box (Rack) Dimension / Capacity
|
37.5" x 19.5" x 6.5" (95 x 49.5 x 16.5 cm) / 90 lb (40.8 kg)/ 400 lb (180 kg) |
| Payload Capacity / Towing Capacity |
1,500 lb (680.4 kg) |
| Cargo System |
Lock & Ride |
| Lighting |
Triple 50w High Beam, Dual 50w Low
Beam Headlights; Dual Brakelights/
Taillights |
| Electronic Power Steering |
Standard |
| Instrumentation |
Digital Gauge, Analog Speedometer, Odometer, Tachometer, Tripmeter, Gear Indicator, Fuel Gauge, AWD Indicator, Hi-Temp/Low-Batt Lights, DC Outlet |
| Colors |
Sage Green, Bright White (EPS only) |
|
|
