| Engine Type |
4-Stroke DOHC Twin Cylinder |
| Displacement |
875cc |
| Fuel System |
Electronic Fuel Injection |
| Cooling |
Liquid |
| Transmission/Final Drive |
Automatic PVT P/R/N/L/H; Shaft |
| Drive System |
On-Demand True AWD/2WD/Turf Mode* |
Engine Braking System/
Active Decent Control |
Not Equipped |
| Front Suspension |
Dual A-Arm Performance Series - FOX 2.0 Podium X with Anti-Sway Bar 10" (25.4 cm) Travel |
| Rear Suspension |
Dual A-Arm Performance Series - FOX 2.0 Podium X with Anti-Sway Bar 10" (25.4 cm) Travel |
| Front/Rear Brakes |
4-Wheel Hydraulic Disc with Dual-Bore Front Calipers |
| Parking Brake |
Park in Transmission |
| Front Tires |
27 x 9-14; GBC Dirt Commander |
| Rear Tires |
27 x 11-14; GBC Dirt Commander |
| Wheels |
Cast Aluminum |
| Wheelbase |
79" (200.7 cm) |
| Estimated Dry Weight |
1247 lb (565.6 kg) |
| Overall Vehicle Size |
106 x 55 x 70.5" (269.2 x 139.7 x 179.1 cm) |
| Ground Clearance |
12.5" (30.5 cm) † |
| Fuel Capacity |
9.5 gal (36 L) |
Bed Box Dimension
|
20.7 x 37 x 7.9" (52.5 x 94 x 20cm) |
| Payload Capacity |
740 lb (335.6 kg) |
| Cargo System |
Lock & Ride, 2 Weather Sealed Storage Boxes |
| Hitch Towing Rating |
1,500 lb (680.4 kg) |
| Hitch Type |
Standard / 1.25" Receiver |
| Lighting |
White LED, High/Low |
| Electronic Power Steering |
Standard |
| Instrumentation |
Polaris Interactive Digital Display, Speedometer, Odometer, Dual Tripmeters, Tachometer, Coolant Temperature, Volt Meter, Hour Meter, Service Reminder, Clock, Gear Indicator, Fuel Gauge, Seatbelt Reminder, Compass, Elevation, Latitude/Longitude, Route Recording & Display, Fault Code Display, Bluetooth Connectivity, USB Port, DC Outlet |
| Colors |
Stealth Black |
|
|
