| Engine Type |
4-Stroke DOHC Twin Cylinder |
| Displacement |
875cc |
| Fuel System |
Electronic Fuel Injection |
| Cooling |
Liquid |
| Transmission/Final Drive |
Automatic PVT P/R/N/L/H; Shaft |
| Drive System |
On-Demand True AWD/2WD/Turf Mode* |
Engine Braking System/
Active Decent Control |
Not Equipped |
| Front Suspension |
Dual A-Arm with Anti-Sway Bar 10" (25.4 cm) Travel |
| Rear Suspension |
Dual A-Arm with Anti-Sway Bar
10" (25.4 cm) Travel |
| Front/Rear Brakes |
4-Wheel Hydraulic Disc with Dual-Bore Front Calipers |
| Parking Brake |
Park in Transmission |
| Front Tires |
26 x 8-12; PXT |
| Rear Tires |
26 x 9-12; PXT |
| Wheels |
Cast Aluminum |
| Wheelbase |
79" (200.7 cm) |
| Estimated Dry Weight |
1,174 lb (532.5 kg)* |
| Overall Vehicle Size |
105 x 50 x 69.5"
(266.7 x 127 x 176.5 cm) |
| Ground Clearance |
11" (27.9 cm)** |
| Fuel Capacity |
9.5 gal (36 L) |
Bed Box Dimension
|
20.7 x 37 x 7.9"
(52.5 x 94 x 20 cm) |
| Payload Capacity |
740 lb (335.6 kg) |
| Cargo System |
Lock & Ride, 2 Weather Sealed Storage Boxes |
| Hitch Towing Rating |
1,500 lb (680.4 kg) |
| Hitch Type |
Standard / 1.25" Receiver |
| Lighting |
Halogen, 55W Low/ 60W High & Red LED Tail / Brake Lights |
| Electronic Power Steering |
Standard |
| Instrumentation |
Digital Gauge, Speedometer, Odometer, Tripmeter,
Tachometer, Coolant Temperature, Volt Meter, Hour Meter, Service Indicator, Clock, Gear Indicator, Fuel Gauge, Hi-Temp Light, Seatbelt Reminder Light, DC Outlet |
| Colors |
White Lightning, Polaris Pursuit Camo, Black Pearl, Sunset Red |
|
|
