2015
Polaris RANGER 570 Full Size
2015
Polaris RANGER 570 Full Size |
|
|
2015 Polaris
RANGER 570 Full Size |
2015 Polaris RANGER 570 Full Size |
| Engine Type |
4-Stroke Single Cylinder |
| Displacement |
567cc |
| Fuel System |
Electronic Fuel Injection |
| Cooling |
Liquid |
| Transmission/Final Drive |
Automatic PVT H/L/N/R/P;
Shaft |
| Drive System |
On-Demand True AWD/2WD/
VersaTrac Turf Mode |
Engine Braking System/
Active Decent Control |
Not Equipped |
| Front Suspension |
Dual A-Arm 10" (25.4 cm) Travel |
| Rear Suspension |
Dual A-Arm, IRS 10" (25.4 cm) Travel |
| Front/Rear Brakes |
4-Wheel Hydraulic Disc with Dual-Bore Front Calipers |
| Parking Brake |
Park In-Transmission |
| Front Tires |
25 x 10-12; 489 |
| Rear Tires |
25 x 11-12; 489 |
| Wheels |
Stamped Steel |
| Wheelbase |
81" (206 cm) |
| Estimated Dry Weight |
1,265 lb (574 kg) |
| Overall Vehicle Size |
116.5 x 60 x 76"
(296 x 152 x 193 cm) |
| Ground Clearance |
12" (30.5 cm) |
| Fuel Capacity |
10 gal (37.9 L) |
Bed Box Dimension
|
36.5 x 54 x 11.5"
(93 x 137 x 29 cm) |
| Payload Capacity |
1,500 lb (680.4 kg) |
| Cargo System |
Lock & Ride, 2 Weather Sealed Storage Boxes |
| Hitch Towing Rating |
2,000 lb (907.2 kg) |
| Hitch Type |
Standard / 2" Receiver |
| Lighting |
55W low/ 60W high, LED Tail |
| Electronic Power Steering |
Not Equipped |
| Instrumentation |
Digital Gauge, Speedometer, Odometer, Tachometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Hi-Temp, Coolant Temperature, Voltmeter, Service Indicator, Seat Belt Reminder, DC Outlets (2) |
| Colors |
Solar Red, Sage Green, Polaris
Pursuit Camo, Turbo Silver (EPS only) |
|
|
|
|
|
|
|
|
|
|
