Engine: |
Liquid-cooled, 90-degree, four-stroke V-twin |
Valve system: |
SOHC, four valves per cylinder |
Displacement: |
749cc |
Starting system: |
Electric |
Bore x stroke: |
85 x 66mm |
Compression ratio: |
9.3:1 |
Fuel injection: |
DFI® with two 36mm Mikuni throttle bodies |
Ignition: |
TCBI with digital advance |
Transmission: |
Continuously variable belt-drive transmission with high and low range, plus reverse, and Kawasaki Engine Brake Control |
Final drive: |
Selectable four-wheel drive with Variable Front Differential Control, shaft |
Frame: |
Double-cradle, high-tensile tubular steel |
Front suspension / wheel travel: |
Double Wishbone/ 6.7” |
Rear suspension / wheel travel: |
Fully independent, dual A-arm / 7.5” |
Front tires: |
AT 25 x 8-12 |
Rear tires: |
AT 25 x 10-12 |
Front brakes: |
Dual hydraulic 200mm discs with 2-piston calipers |
Rear brake: |
Sealed, oil-bathed, multi-disc |
Overall length: |
86.4” |
Overall width: |
46.5” |
Overall height: |
48.0” |
Wheelbase: |
50.6” |
Turning Radius: |
10’ 6” |
Ground clearance: |
9.4” |
Seat height: |
35.8” |
Lighting: |
35W headlights, 5W taillight, 21W stoplight |
Rack capacity, front / rear: |
88 lb / 176 lb |
Total rack capacity: |
242 lb |
Towing capacity: |
1,250 lb |
Curb weight: |
694.6 lb |
Fuel capacity: |
5 gallons |
Instruments: |
Speedometer, odometer, dual trip meters, fuel gauge, engine temp, clock, hour meter and 2WD/4WD icon, plus indicators for EPS, neutral, belt, and oil pressure. |
Color choices: |
Super Black & Metallic Stardust White |
MSRP: |
$TBD |
Warranty: |
12 Months |
Good Times™ Protection Plan (optional) |
12, 24, 36 or 48 months |
Wholesale distributor: |
Kawasaki Motors Corp., U.S.A.
9950 Jeronimo Road
Irvine, CA 92618
949-770-0400
www.kawasaki.com |
