ENGINE |
|
| Type |
799.9 cc V-twin, liquid-cooled, SOHC, 8-valve (4-valve / cyl) |
| Bore
& Stroke |
91 x 62 mm |
| Fuel
Delivery |
46 mm Throttle Body, 2 Siemens VDO injectors |
| Starting
System |
Electric |
| Transmission |
CVT, sub-transmission with high, low, park, neutral & reverse.
Standard engine braking |
| Drive
Train |
Selectable 2WD / 4WD shaft driven with Visco-Lok‡ QE auto-locking front differential |
| CHASSIS |
Frame
|
Surrounding
Spar Technology (SST) G2 |
| Front
Suspension Type |
Double A-arm |
| Rear
Suspension Type |
Torsional Trailing arm Independent (TTI) |
| Front
Brake |
Dual 214 mm ventilated disc brakes with hydraulic twin-piston calipers |
| Rear
Brake |
Single 214 mm ventilated disc brake with hydraulic twin-piston calipers |
| Tires
/Front |
30 x 9 x 14 in. |
| Tires
/Rear |
30 x 9 x 14 in. |
| Wheels |
Steel Black |
| DIMENSIONS |
| L
x W x H |
97 x 50 x 51.5 in. |
Wheelbase
|
59 in. |
Seat
Height
|
36.75 in. |
| Ground
Clearance |
13 in. |
| Towing
Capacity |
1,300 lbs (590
kg) |
| Rack
Capacity |
200 lb |
| Rear
Storage |
5.7 gal |
| Fuel
Capacity |
5.4
gal |
| FEATURES |
| Instrumentation |
Multifunction digital LCD gauge: Speedometer, tachometer (bar graph RPM, bottom bar numerical RPM), odometer, trip & hour meters, diagnostic center, gear position, engine hour meter, 4 x 4 indicator, temperature and engine lights, fuel gauge, clock, auto shut off |
| Electrical |
Prewired for
winch |
| Lighting |
230-W from twin 60-W projectors and dual 55-W reflectors with tail light / brake light |
| DC
Outlet |
Lighter-type
in console, Standard connector at the back
(15A) |
| WARRANTY |
| Factory |
6 months limited warranty |
| Extended |
B.E.S.T available from 12 to 36 months |
