| Type |
449cc liquid-cooled
w/fan, 4-stroke;
DOHC, 5 titanium valves |
| |
| Bore x Stroke |
95.0 x 63.4mm |
| |
| Compression Ratio |
11.4:1 |
| |
| Carburetion |
Keihin 39mm FCR w/throttle
position sensor |
| |
| Ignition |
DC-CDI |
| |
| Starting System |
Electric |
| |
| Transmission |
5-speed; wet multiplate clutch |
| |
| Drive Train |
2WD; sealed O-ring chain,
eccentric adjustment |
| |
| |
| Suspension/Front |
Independent double wishbone,
w/piggy back High-/Lo-speed compression, rebound
and threaded preload adjustment, 9.1-in travel |
| |
| Suspension/Rear |
Cast aluminum swing arm w/rebound,
High-/Lo-speed compression and threaded preload,
10.6-in travel |
| |
| Brakes/Front |
Dual ventilated hydraulic
disc, twin piston |
| |
| Brakes/Rear |
Ventilated hydraulic disc,
twin piston |
| |
| Tires/Front |
AT21 x 7-10 Radial |
| |
| Tires/Rear |
AT20 x 10-9 Radial |
| |
| |
| L x W x H |
72.4 x 46.1 x 42.9 in |
| |
| Seat Height |
31.9" |
| |
| Wheelbase |
50.4" |
| |
| Ground Clearance |
4.5" |
| |
| Fuel Capacity |
2.6 gal. |
| |
| Dry Weight |
350 lb. |
| |
| |
| Lighting |
Dual 30W Krypton multireflector
headlights & 3.9/0.5W LED brakelight |
| |
| Color |
Team Yamaha Blue/White; Gray/Red;
Special Edition Orange/Black |
| |
