| Engine |
Liquid-cooled, 90-degree,
four-stroke V-twin
SOHC, four valves per cylinder |
|
| |
| |
| |
| Carburetion |
(2) Keihin CVKR-34 |
|
| Starting |
Electric / Digital DC-CDI |
|
| Transmission |
Continuously variable
belt-drive transmission with high and
low range, plus reverse, and Kawasaki
Engine Brake Control |
|
| Final drive |
Selectable four-wheel
drive with Variable Front Differential
Control, shaft |
|
| Frame type |
Double-cradle, high-tensile
tubular steel |
|
| Front suspension /
wheel travel |
Dual A-arm / 6.7 in. |
|
| Rear suspension / wheel
travel |
Fully Independent, dual
A-arm / 7.9 in. |
|
| |
| |
| Front brakes |
Dual hydraulic 200mm discs
with 2-piston calipers |
|
| Rear brake |
Sealed, oil-bathed, multi-disc |
|
| |
| |
| |
| |
| |
| Lighting |
(4) 40W headlights, 5W
taillight, 21W stoplight |
|
| Rack capacity,
front / rear: |
88 / 176 lbs. |
|
| Towing capacity |
1,250 lbs. |
|
| |
| |
| Instruments |
Speedometer, odometer,
dual trip meters, clock, hour meter,
fuel gauge, 2x4/4x4 indicator, neutral
indicator, reverse indicator, low fuel
warning light, low oil warning light |
|
| Standard Colors |
Woodsman Green, Lime Green,
Sunbeam Red, Super Black, REALTREE™
Hardwoods Green® HD. Special:
Candy Thunder Blue |
|
| MSRP standard
/ camo / special: |
$7,799 / $8,149 / $8,049 |
|
