| Engine |
Air-cooled, SOHC, four-stroke,
single cylinder |
|
| |
| Bore x stroke |
80.0 x 72.0mm |
|
| |
| |
| Starting |
Electric with recoil backup |
|
| Transmission |
Continuously variable
transmission with Kawasaki Engine Brake
Control, high and low range, plus reverse |
|
| |
| Frame type |
Double cradle, steel |
|
| Front suspension /
wheel travel |
MacPherson strut / 6.7
in. |
|
| Rear suspension / wheel
travel |
Swingarm with single shock,
preload adjustment / 7.1 in. |
|
| Front tires |
AT25x8-12 tubeless |
|
| Rear tires |
AT25x10-12 tubeless |
|
| Front brakes |
Dual hydraulic discs |
|
| Rear brake |
Sealed, oil-bathed, multi-disc |
|
| |
| |
| |
| |
| Ground clearance |
At center of chassis,
10.2 / at differential, 7.7 in. |
|
| |
| |
| Rack capacity, front
/ rear |
88 / 154 lbs. |
|
| Towing capacity |
1,100 lbs. |
|
| |
| |
| |
| Color choices |
Woodsman Green or Aztec
Red |
|
| Good Times™ Protection
Plan |
12, 24, 36 or 48 months |
|
| |
