| Engine |
Liquid-cooled, 90-degree,
four-stroke V-twin |
|
| Valve system |
SOHC, four valves per
cylinder |
|
| |
| |
| |
| |
| Carburetion |
(2) Keihin CVKR-34 |
|
| |
| Transmission |
Continuously variable
belt-drive transmission with high and
low range, plus reverse, and Kawasaki
Engine Brake Control |
|
| Final drive |
Selectable four-wheel
drive with Variable Front Differential
Control, shaft |
|
| Frame |
Double-cradle, tubular
steel |
|
| Front suspension /
wheel travel |
Dual A-arm / 6.7 in. |
|
| Rear suspension / wheel
travel |
Fully Independent, dual
A-arm / 7.9 in. |
|
| |
| |
| Front brakes |
Dual hydraulic discs with
2-piston calipers |
|
| Rear brake |
Sealed, oil-bathed, multi-disc |
|
| |
| |
| |
| |
| Ground clearance |
10.6 in. |
|
| |
| Lighting |
(4) 40W headlights, 5W
taillight, 21W stoplight |
|
| Rack capacity, front
/ rear |
88 / 176 lbs. |
|
| Towing capacity |
1,250 lbs. |
|
| |
| |
| Instruments |
Speedometer, odometer,
dual trip meters, clock, hour meter,
fuel gauge, 2x4/4x4 indicator, neutral
indicator, reverse indicator, low fuel
warning light, low oil warning light |
|
| Color choices |
Candy Thunder Blue, Aztec
Red, REALTREE Hardwoods® Green HD™,
Woodsman Green, Lime Green, New Black
or Advantage® MX-1™ HD™ |
|
| Good Times™ Protection
Plan |
12, 24, 36 or 48 months |
|
| |
