| Engine |
Air-cooled,
SOHC, four-stroke, single cylinder |
|
|
| Bore
x Stroke |
80.0
x 72.0mm |
|
|
|
| Starting
System |
Electric
with recoil backup |
|
| Transmission |
Continuously
variable transmission with Kawasaki
Engine Brake Control, high and
low range, plus reverse |
|
| Final
drive |
Selectable
four-wheel drive with Variable
Front Differential Control, shaft |
|
| Frame
type |
Double
cradle steel |
|
| Front
suspension / wheel travel |
MacPherson
strut / 6.7 in. |
|
| Rear
suspension / wheel travel |
Swingarm
with single shock, preload adjustment
/ 7.1 in. |
|
| Front
Tire Size |
AT25x8-12
tubeless |
|
| Rear
Tire Size |
AT25x10-12
tubeless |
|
| Front
brakes |
Dual
hydraulic discs |
|
| Rear
Brakes |
Sealed,
oil-bathed, multi-disc |
|
|
|
|
|
| Ground
clearance |
At
center of chassis, 9.3 / at rear
axle, 7.3 in. |
|
|
|
| Rack
capacity, front / rear |
88
/ 154 lbs. |
|
| Towing
capacity |
1,100
lbs. |
|
|
|
|
| Color
Choices |
Realtree®
APG™ HD® camouflage |
|
| Good
Times™ Protection Plan |
12,
24, 36 or 48 months |
|
|
