| Engine |
Liquid-cooled,
90-degree, four-stroke V-twin |
|
| Valve
system |
SOHC,
four valves per cylinder |
|
|
|
|
|
| Fuel
Injection |
DFI;
(2) 36mm Mikuni throttle
bodies |
|
| Ignition |
TCBI
with digital advance |
|
| Transmission |
Continuously
variable belt-drive transmission
with high and low range,
plus reverse, and Kawasaki
Engine Brake Control |
|
| Final
drive |
Selectable
four-wheel drive with Variable
Front Differential Control,
shaft |
|
| Frame
Type |
Double-cradle,
high tensile tubular steel |
|
| Front
suspension / wheel travel |
Dual
A-arm / 6.7 in. |
|
| Rear
suspension / wheel travel |
Fully
Independent, dual A-arm
/ 7.9 in. |
|
| Front
Tire Size |
AT25x8-12 |
|
| Rear
Tire Size |
AT25x10-12 |
|
| Front
brakes |
Dual
hydraulic 200mm discs with
2-piston calipers |
|
| Rear
Brakes |
Sealed,
oil-bathed, multi-disc |
|
|
|
|
|
|
|
| Lighting |
(4)
40W headlights, 5W taillight,
21W stoplight |
|
| Rack
capacity, front / rear |
88
/ 176 lbs. |
|
| Towing
capacity |
1,250
lbs. |
|
|
|
| Instruments |
Speedometer,
odometer, dual trip meters,
clock, hour meter, fuel
gauge, 2x4/4x4 indicator,
neutral indicator, reverse
indicator, low fuel warning
light, low oil warning light |
|
| Color
Choices |
Dark
Royal Red, Woodsman Green,
painted Metallic Ruby Red |
|
| Good
Times™ Protection Plan |
12,
24, 36 or 48 months |
|
|
