| Engine |
Four-stroke,
V-twin, liquid-cooled, SOHC, four-valve |
|
|
| Starting
system |
Electric
with recoil back up |
|
|
|
| Carburetion |
(2)
Keihin CVKR-D32 |
|
|
| Transmission |
Dual-range
CVT plus reverse with Kawasaki
Engine Brake Control |
|
| Final
drive |
2x4
/ 4x4 shaft |
|
| Frame
Type |
Double
cradle, tubular steel |
|
| Front
suspension / wheel travel |
MacPherson
/ 6.7 in. |
|
| Rear
suspension / wheel travel |
Aluminum
swingarm and single shock / 7.2
in. |
|
| Front
Tire Size |
AT25x8-12 |
|
| Rear
Tire Size |
AT25x10-12 |
|
| Front
brakes |
(2)
Dual-piston disc |
|
| Rear
Brakes |
Sealed,
oil-bathed, multi-disc |
|
|
|
|
| Ground
clearance |
At
center of chassis, 9.0 / at rear
axle, 7.3 in. |
|
|
| Lighting,
headlights |
(2)
45-watt headlights, taillight,
brake light |
|
| Total
rack capacity |
264
lbs. |
|
| Towing
capacity |
1,250
lbs. |
|
|
|
| Instruments |
Speedometer,
odometer, dual trip meters, clock,
hour meter, fuel gauge, 2x4 /
4x4 indicator light, neutral indicator
light, reverse indicator light,
low fuel warning light, low oil
warning light |
|
| Color
Choices |
Smoky
Blue, Super Black |
|
| Good
Times™ Protection Plan |
12,
24, 36 or 48 months |
|
|
