| Engine |
Liquid-cooled,
90-degree, four-stroke V-twin
SOHC, four valves per cylinder
|
|
|
|
|
|
|
|
| Carburetion |
2
x Mikuni 34 mm throttle bodies |
|
|
|
| Transmission |
Continuously
variable belt-drive transmission
with high and low range, plus
reverse, and Kawasaki Engine Brake
Control |
|
| Final
drive |
Selectable
four-wheel drive with Variable
Front Differential Control, shaft |
|
| Frame
type |
Large
diameter, thin-walled, high-tensile
tubular steel |
|
| Front
suspension / wheel travel |
Adjustable
dual A-arm with gas charged shocks
/ 7.5 in. |
|
| Rear
suspension / wheel travel |
Adjustable
Independent Rear Suspension (IRS)
with gas charged, reservoir shocks
/ 7.5 in. |
|
| Front
tires |
Maxxis
26x8-12 |
|
| Rear
tires |
Maxxis
26x10-12 |
|
| Front
brakes |
Dual
hydraulic discs with 2-piston
calipers |
|
| Rear
brake |
Sealed,
oil-bathed, multi-disc |
|
|
|
|
|
|
|
|
|
| Ground
clearance |
11.6
in. |
|
| Lighting |
(2)
40W headlights, (2) 8W taillight,
27W stoplight |
|
| Cargo
bed capacity |
500
lbs, 44.2 W x 32.7 L x 11.1 in. |
|
| Towing
capacity |
1,300
lbs. |
|
|
|
|
|
| Instruments |
Multi-Function
Digital Meter with speedometer,
fuel gauge, clock hour meter,
odometer, dual trip meter and
parking brake, R/N/P/4WD, water
temp and oil pressure indicators |
|
| Standard
Colors |
Metallic
Ruby Red |
|
|
|
