| Engine |
Four-stroke,
liquid-cooled, overhead valve
V-twin |
|
| |
| |
| |
| Carburetor |
Digital
Fuel Injection |
|
| Air
filter |
Snorkel-type
with cyclone-type two-stage dry
replaceable element |
|
| Oil
filter |
Automotive-type
spin-on canister |
|
| Ignition |
Digital
electronic |
|
| Electrical |
12V
DC, 18 amp-hour battery, alternator |
|
| Transmission |
Continuously
variable transmission (CVT) with
high and low range, forward, and
reverse, 2WD/4WD |
|
| Final
drive |
Shaft,
selectable four-wheel drive with
dual-model differential |
|
| Exhaust |
Muffler
with USFS-approved spark arrestor |
|
| |
| Front
suspension / wheel travel |
Independent,
MacPherson strut / 3.9 in. |
|
| Rear
suspension / wheel travel |
Semi-independent,
De Dion axle with leaf springs
and shocks / 2.8 in. |
|
| |
| Brakes |
Four-wheel
hydraulic drums, sealed |
|
| |
| |
| |
| |
| |
| |
| |
| Roll
over protective structure (ROPS) |
This
structure meets ROPS requirements
for wheeled tractors under SAE
J1194, 7.1.1, 7.1.2, and 7.5.
This structure also meets FMVSS
216 Roof Crush resistance requirement |
|
| Cargo
bed dimensions (LxWxH) |
46.3
x 51.6 x 11.3 /15.6 cu. Ft. |
|
| |
| Cargo
bed capacity |
800
lbs. |
|
| Towing
capacity |
1,200
lbs. |
|
| |
| Top
speed |
25
mpg, governed |
|
| Lights |
(2)
30-watt sealed-beam headlights,
(2) 5/21-watt taillight/stoplight |
|
| Instruments |
Parking
brake warning light, coolant temperature
warning light, horn, 12V DC outlet,
speedometer |
|
| Color
choices |
Woodsman
Green, Dark Royal Red |
|
| Good
Times™ Protection Plan |
12
or 24 months |
|
| |
