| Engine
and Electrical |
| Type
|
4-cycle
gas, Electronic Fuel Injection
(EFI) - Closed Loop System |
| Cylinders/Valving |
V-Twin,
OHV |
| Horsepower* |
62 (46.2
kw) |
| Displacement |
839 cc |
| Maximum
torque |
57.5 (42.4
ft lbs) @ 4000 rpm |
| Cooling |
system
Liquid |
| Battery |
340 CCA |
| Alternator |
38 amp
@ 7250 rpm,13.5V - regulated |
| Lights |
| Headlights |
Four 27
watt halogen |
| On-demand
true 4WD system |
| Front
Differential |
Selectable
Limited Slip and Full locking |
| Rear |
Differential
Locked (full-time) |
| Transmission
Type |
Enclosed
and sealed Continuously
Variable Transmission (CVT) |
| Ground
speed, mph (km/h) |
0-53 (0-85)
Hi Forward, 0-30 (0-48)
Lo Forward, 0-15 (0-24)
Reverse |
| Transaxle |
Two speed,
oil bath |
| Front/Rear
Brakes |
Front/rear
hydraulic disk |
| Park
brake |
Foot brake;mechanical
actuation |
| Wheel
Bearings |
Sealed,
double-row ball |
| Suspension
and Steering |
| Front
Suspension |
Independent;double
A-arm with coil over shocks
& anti-sway bar |
| Front
Suspension Travel |
9in. (229mm) |
| Rear
Suspension |
Independent;
Semi-trailing double A-arm
with coil over shocks &
anti-sway bar |
| Rear
Suspension Travel |
9in. (229mm) |
| Turning
radius |
19.7 ft.
(6.0 m) |
| Hitches |
| Front
and Rear |
Optional
2-in receiver (front), Standard
2-in receiver (rear) |
| Roll-Over
Protective Structure (ROPS) |
| Tubular
overhead structure |
1.75 in
(44.4 mm) steel tube |
| Seat
belts |
3-point
seat belts |
| Certification |
ISO 3471
and OSHA ROPS |
| Ground
Clearance |
| Ground
Clearance |
Front
10.3 in. (26.2 cm) |
| Under
Foot Platform |
10.3 in.
(26.2 cm) |
| Dimensions |
| Length |
119 in.
(302) |
| Width |
56.5 (143.5) |
| Front/Rear-tread
Centers |
48in.
(1220mm)/46 in. (1170mm) |
| Height
(with OPS) |
72 in.
(183mm) |
| Wheelbase |
77.8 (1975mm) |
| Weight
(dry), lb. (kg) |
1360 lb
(617 kg) |
| Towing
Capacity |
1200 lb.
(544 kg) |
| Payload
Capacity |
800 lb.
(363kg) |
| Seating |
Capacity
2 |
| Cargo
Box |
| Material |
Composite |
| Dimensions,
in. (mm) |
32.3L
x 47.6W x 11.7D (82cm L
x 120.9cm Wx 29.7cm D) |
| Volume |
8.9 cu.
ft. (0.25) |
| Weight |
400 lb.
(181 kg) |
| Dump |
2-sided
- Manual release |
| Tailgate |
1 handed
release; Hinged at bottom;
Removeable without tools |
| Tires,
Front / Rear |
| Maxxis
Big Horn 2.0, Radial |
26x8-14/26x10-14
(w/alloys) optional on base |
| Ancla
MT (Mud Terrain) |
25x8-12/25x10-12
(w/ steel) |
| Terrahawk
AT (All Terrain) |
n/a |
| Color |
| Options |
Green/Yellow,
Olive/Black, Camo |
| Storage |
| Front |
Sealed
oversized Glove Box, Under
hood storage 1.82 ft3 (0.052m3) |
