| Model: |
TRX250TE
(with ESP) / TRX250TM |
| Engine
Type: |
229cc
air-cooled OHV longitudinally
mounted single-cylinder
four-stroke |
| Bore
and Stroke: |
68.5mm
x 62.2mm |
| Carburetion:
|
22mm
Carburator |
| Ignition:
|
CD with
electronic advance |
| Starter: |
Electric
with auxiliary recoil |
| Clutch:
|
Automatic |
| Transmission:
|
ESP five-speed
with Reverse / Five-speed
with Reverse |
| Driveline:
|
Direct
rear driveshaft |
| Suspension |
Front:
Independent double-wishbone;
5.1 inches travel
Rear: Swingarm with
single shock; 4.9 inches
travel |
| Brakes |
Front:
Dual sealed hydraulic
drum
Rear: Sealed mechanical
drum |
| Tires |
Front:
22 x 7-11
Rear: 22x 10-9 |
| Length:
|
75.0
inches |
| Width:
|
40.7
inches |
| Height: |
42.1
inches |
| Seat
Height: |
31.2
inches |
| Ground
Clearance: |
6.0
inches |
| Wheelbase:
|
44.5
inches |
| Turning
Radius: |
8.5 feet
|
| Curb**
Weight: |
439 pounds
(TRX250TE)
432 pounds (TRX250TM) |
| Fuel
Capacity: |
2.6 gallons,
including 0.7 gallon reserve |
| Colors: |
Red,
Olive, Blue |
| **Includes
all standard equipment,
required fluids and a
full tank of fuel-ready
to ride. |
| Recommended
for riders 16 years of
age and older. |
