| Model: |
TRX450R (kick start) /
TRX450ER (electric start) |
| Engine Type: |
450cc liquid-cooled single-cylinder
four-stroke |
| Bore and Stroke: |
96mm x 62mm |
| Compression Ration: |
12.0:1 |
| Valve Train: |
Unicam; four-valve; 36mm
intake, Ti; 30mm exhaust, steel |
| Induction: |
Keihin 40mm flat slide
carburetor with throttle position sensor
(TPS) |
| Ignition: |
CD with electronic advance |
| Starter: |
Electric or forward kick |
| Transmission: |
Five-speed |
| Final Drive: |
O-ring-sealed chain |
| Suspension |
Front: Independent double-wishbone
with Showa shocks, featuring adjustable
spring preload, rebound and compression
damping; 8.4 inches travel
Rear: Pro-Link with single Showa shock featuring
adjustable spring preload, rebound and compression
damping; 9.3 inches of travel |
| Brakes |
Front: Dual hydraulic 174mm
discs with twin-piston calipers
Rear: Single hydraulic 190mm disc with single-piston
caliper |
| Tires |
Front: 21 x 7-10 knobby
radial
Rear: 20 x 10-9 knobby radial |
| Length: |
73.3 inches |
| Width: |
46.3 inches |
| Height: |
43.3 inches |
| Seat Height: |
32.8 inches |
| Ground Clearance: |
4.4 inches |
| Wheelbase: |
50.2 inches |
| Fuel Capacity |
2.7 gallons, including
0.8-gallon reserve |
| Colors: |
White with Orange
frame |
| Curb Weight*: |
383 pounds (TRX450R) /
390 pounds (TRX450ER) |
*Includes all
standard equipment, required fluids and
full tank of fuel--ready to ride.
Meets current CARB off-road emissions standards.
Consult owner's manual for optional HRC
Racing Kit parts.
For highly experienced riders 16 years of
age and older. |
