Automatic CVT with EBS, Hi/Lo Range, Reverse & Park
Drive System
2/4 WD + Electric Diff Lock
Overall
Width
47.5/120.6
Overall
Height
48/121.9
Overall
Length
86.5/219.7
Wheel Base
50/127
Suspension
Travel Front
10/25.4
Suspension
Travel Rear
10/25.4
Ground Clearance
11/27.9
Suspension
Type - Front
Double A-Arm
Suspension
Type - Rear
Double A-Arm
Front Brakes
Hydraulic Disc
Rear Service Brake
Hydraulic Disc
Tire Front
25x8-12
Tire Rear
25x10-12
Max Fuel
Capacity
5.7/21.6
Front Rack Capacity
100/45.4
Rack/Box Capacity
200/90.8
Towing Capacity
1050/476.3
Alternator
Capacity
28 Amps
Speedometer
Digital
Odometer
Digital
Dry Weight (lbs)
676/307
Available Colors
Steel Blue Metallic Paint, Desert Red Metallic Paint, Camo
Special Features
Power Steering, Aluminum Wheels, Automotive-Style Paint (Non- Camo Models), Sway Bar, Heavy-Duty Front & Rear Bumpers, Rear 2" Receiver, Front & Rear SpeedRacks, 3000-lb. Winch, Duro 2 Star Kaden Tires
