Displacement
(cc) |
695cc |
Engine Type |
SOHC, 4-Stroke, 4-Valve w / EFI |
Bore &
Stroke (mm) |
102x85 |
Cooling
System |
liquid w/fan |
Transmission |
Automatic CVT with EBS, Hi / Lo Range, Reverse & Park |
Drive System |
2/4 WD + Electric Front Differential Lock |
Overall
Size |
129x60x79 (327.7x152.4x200.7) |
Wheel Base |
85 (215.9) |
Suspension
Travel Front |
10/25.4 |
Suspension
Travel Rear |
10/25.4 |
Ground Clearance |
10 (25.4) |
Suspension
Type - Front |
Double A-Arm |
Suspension
Type - Rear |
Double A-Arm |
Front Brakes |
Hydraulic Disc |
Rear Brakes |
Hydraulic Disc |
Tire Front |
Duro Kaden / 26x9R14 |
Tire Rear |
Duro Kaden / 26x11R14 |
| Wheels |
Aluminum |
Max Fuel
Capacity |
8.2 / 31L |
Rack/Box Capacity |
600 (272.2) Cargo Box |
Towing Capacity |
1500 (680.4) |
| Hitch Type |
Rear 2" Receiver |
Alternator
Capacity |
28 Amps |
Instrumentation |
Digital |
Lighting |
Dual Halogen Headlight / Rear Taillight |
| Dry Weight (lbs) |
1363 (618.2) |
| Available Colors |
Vibrant Red Metallic Paint, True Timber Camo,
Emerald Green Metallic Paint |
| Additonal Features |
3-Passenger Seat, Automotive-Style Paint (Non-Camo Models),
Dashboard Shift Lever with Park, Rear FOX FLOAT Coil-Over Shocks,
Side Storage Compartments, Sleek Side Restraints, Transformable Tilt
Rear Cargo Box, Underhood Storage Compartment |
|
|
