| Engine Type |
4-Stroke Single Cylinder |
| Displacement |
567cc |
| Fuel System |
Electronic Fuel Injection |
| Cooling |
Liquid |
| Transmission/Final Drive |
Automatic PVT H/L/N/R/P;
Shaft |
| Drive System |
On-Demand True AWD/2WD/
VersaTrac Turf Mode |
Engine Braking System/
Active Decent Control |
Not Equipped |
| Front Suspension |
Dual A-Arm 10" (25.4 cm) Travel |
| Rear Suspension |
Dual A-Arm, IRS 10" (25.4 cm) Travel |
| Front/Rear Brakes |
4-Wheel Hydraulic Disc with Dual-Bore Front Calipers |
| Parking Brake |
Park In-Transmission |
| Front Tires |
26 x 9-12; PXT |
| Rear Tires |
26 x 11-12; PXT |
| Wheels |
Stamped Steel |
| Wheelbase |
81" (206 cm) |
| Estimated Dry Weight |
1,535 lb (696 kg)
EPS: 1,551 lb (704 kg) |
| Overall Vehicle Size |
148.5 x 61 x 76"
(377 x 155 x 193 cm) |
| Ground Clearance |
11.3" (28.7 cm) |
| Fuel Capacity |
10 gal (37.9 L) |
Bed Box Dimension / Capacity
|
36.5 x 54 x 11.5" (93 x 137 x 29 cm) / 1,000 lb (453.6 kg) |
| Payload Capacity |
2,000 lb (907.2 kg) |
| Cargo System |
Lock & Ride, 2 Weather Sealed Storage Boxes |
| Hitch Towing Rating |
11,500 lb (680.4 kg) |
| Hitch Type |
Standard / 2" Receiver |
| Lighting |
55W low/ 60W high, LED Tail |
| Electronic Power Steering |
Available EPS |
| Instrumentation |
Digital Gauge, Speedometer, Odometer, Tachometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Hi-Temp, Coolant Temperature, Voltmeter, Service Indicator, Seat Belt Reminder, DC Outlets (2) |
| Colors |
Solar Red, Sage Green, Polaris Pursuit Camo (non-EPS) EPS only, White Lightning, Sunset Red, Super Steel Gray, Black Pearl, Hunter Edition |
|
|
|
