| ENGINE |
|
| Type |
976 cc V-twin, liquid-cooled, SOHC, 8-valve (4-valve / cyl) |
| Bore
& Stroke |
91 x 75 mm |
| Fuel
Delivery |
iTC™ with EFI and 54 mm Throttle Body, 2 Siemens† VDO injectors |
| Starting
System |
Electric |
| Transmission |
CVT, sub-transmission with high, low, park, neutral & reverse.
Standard engine braking |
| Drive
Train |
Selectable 2WD / 4WD shaft driven with Visco-Lok‡ auto-locking front differential* |
| CHASSIS |
Frame
|
Steel |
Cage Type
|
2-in. (5.1 cm) diameter, high-strength steel, ROPS-approved |
| Steering Wheel Adjustment |
Adjustable tilt steering |
| Front
Suspension Type |
Double A-arm with dive-control geometry / Motion Control shocks |
| Front
Travel |
10 in. |
| Rear
Suspension Type |
Torsional Trailing arm Independent rear suspension (TTI) with external sway bar / Motion Control shocks |
| Rear
Travel |
10 in. |
| Front
Brake |
Dual 214 mm ventilated disc brakes with hydraulic twin-piston calipers |
| Rear
Brake |
Single 214 mm ventilated disc brake with hydraulic twin-piston calipers |
| Tires
/Front |
Carlisle Black Rock 27 x 9 x 12 in. |
| Tires
/Rear |
Carlisle Black Rock 27 x 11 x 12 in. |
| Wheels |
Cast-aluminum |
| DIMENSIONS |
| Dry
Weight |
1,321 lb |
| L
x W x H |
118.3 x 58.6 x 72 in. |
Wheelbase
|
75.8 in. |
Seat
Height
|
34.5 in. |
| Ground
Clearance |
11 in. |
| Towing
Capacity |
1,500 lb |
| Cargo Box
Capacity |
Total: 600 lb / Upper: 400 lb / Lower: 200 lb |
| Cockpit storage |
Glove box: 4.5 gal / Under driver seat: 3.5 gal / Center console: 0.3 gal |
| Fuel
Capacity |
10 gal |
| FEATURES |
| Instrumentation |
Multifunction digital gauge: Speedometer, tachometer,
odometer, trip and hour meters, fuel, gear position, sport mode,
ECO™ mode, seat belt and 4 x 4 indicator, diagnostics, clock, auto shut off |
| Anti-theft System |
Digitally Encoded Security System (D.E.S.S.™ ) |
| Electrical |
Prewired for
winch |
| Lighting |
240-W from four 60-W projectors with tail lights / brake light |
| DC
Outlet |
Lighter type in console, standard connector in the back (15-A) |
| WARRANTY |
| Factory |
6 months limited warranty |
| Extended |
B.E.S.T. available from 6 to 30 months |
