| Type |
421cc liquid-cooled w/fan SOHC
4-stroke single |
| |
| Bore x Stroke |
84.5mm x 75mm |
| |
| Compression Ratio |
10.0:1 |
| |
| Carburetion |
Mikuni 33mm BSR |
| |
| Ignition |
DC - CDI |
| |
| Starting System |
Electric |
| |
| Transmission |
Yamaha Ultramatic® V-Belt / F,N,R |
| |
| Engine Braking |
Front & Rear Wheel |
| |
| Drive Train |
Yamaha On-Command® push button
2WD, 4WD ; Shaft |
| |
|
| |
| Suspension/Front |
Independent Double Wishbone,
6.3" travel w/5-way preload adjustment |
| |
| Suspension/Rear |
Swingarm, 7.1" travel w/5-way
preload adjustment |
| |
| Brakes/Front |
Dual Hydraulic Discs |
| |
| Brakes/Rear |
Hydraulic Disc |
| |
| Tires/Front |
AT23 x 8-12 radial |
| |
| Tires/Rear |
AT23 x 10-12 radial |
| |
|
| Length |
77.9" |
| |
| Width |
41.9" |
| |
| Height |
43.1" |
| |
| Seat Height |
33.1" |
| |
| Wheelbase |
48.5" |
| |
| Turning Radius |
118" |
| |
| Ground Clearance |
8.7" |
| |
| Fuel Capacity |
3.8 Gallons |
| |
| Dry Weight |
516 lbs |
| |
| Rack Capacity |
N/A |
| |
| Towing Capacity |
1102 Lbs. (with optional hitch) |
| |
|
| Instrumentation |
Digital speedometer, odometer
& fuel gauge |
| |
| Lighting |
Dual 30W Krypton multireflector
headlights & 21/5W brake light |
| |
