| Type |
421cc
liquid-cooled w/fan, 4-stroke; SOHC, 4 valves |
|
| Bore
x Stroke |
84.5 x
75mm |
|
| Compression
Ratio |
10:1 |
|
| Carburetion |
Mikuni
33mm BSR |
|
| Ignition |
DC–CDI |
|
| Starting
System |
Electric |
|
| Transmission |
Yamaha
Ultramatic® V-belt with all-wheel engine
braking/H, L, N, R |
|
|
| Drive
Train |
Yamaha
On-Command® pushbutton; 3-way locking
differential; 2WD, 4WD, locked 4WD; shaft
drive |
|
|
| |
|
| |
| Suspension/Front |
Independent
double wishbone; 5-way preload adjustment,
7.3-in travel |
|
| Suspension/Rear |
Independent
double wishbone;
5-way preload adjustment, 7.3-in travel |
|
| Brakes/Front |
Dual hydraulic
disc, twin piston |
|
| Brakes/Rear |
Dual hydraulic
disc |
|
| Tires/Front |
AT25x8-12
NHS |
|
| Tires/Rear |
AT25x10-12
NHS |
| |
|
| L
x W x H |
113.6
x 54.4 x 73 in |
|
| Wheelbase |
75.2” |
|
| Turning
Radius |
153.5” |
|
| Ground
Clearance |
12.1" |
|
| Fuel
Capacity |
7.9 gal. |
|
| Dry
Weight |
1,031
lb |
|
| Bed
Capacity |
400 lb. |
|
| Towing
Capacity |
1212 lb. |
|
| |
|
|
| Instrumentation |
Fuel sight
gauge, 4WD Indicator lights (optional digital
speedo/fuel) |
|
| Lighting |
Dual 30W
Krypton multireflector headlights &
dual 21/5W brake light |
|
| Color |
Red; Hunter
Green; Realtree® AP HD™ Camouflage |
|
| |
