| Type |
401cc liquid-cooled
w/fan, SOHC 4-stroke single |
|
| Bore
x Stroke |
84.5mm x 71.5mm |
|
| Compression
Ratio |
10.5:1 |
|
| Carburetion |
Mikuni 33mm BSR |
|
| Ignition |
DC-CDI |
|
| Starting
System |
Electric w/auxiliary
pull |
|
| Transmission |
Yamaha Ultramatic®
V-belt/F, N, R |
|
| Engine
Braking |
Front & rear
wheel |
|
| Drive
Train |
Yamaha On-Command®
pushbutton 2WD & 4WD; shaft |
| |
|
| |
| Suspension/Front |
Independent double
wishbone, 6.3" travel w/5-way preload adjustment |
|
| Suspension/Rear |
Independent double
wishbone, 7.1" travel w/5-way preload adjustment |
|
| Brakes/Front |
Dual hydraulic
discs |
|
| Brakes/Rear |
Hydraulic disc |
|
| Tires/Front |
AT25x8-12 |
|
| Tires/Rear |
AT25x10-12 |
| |
|
| Length |
78.5" x 43.0"
x 44.1" |
|
| Seat
Height |
32.7" |
|
| Wheelbase |
48.5" |
|
| Turning
Radius |
118" |
|
| Ground
Clearance |
10.8" |
|
| Fuel
Capacity |
4.0 gal. |
|
| Dry Weight |
578 lb. |
|
| Rack
Capacity |
88 lb front/176
lb rear |
|
| Towing
Capacity |
1102 lb. |
| |
|
| Instrumentation |
Speedometer, odometer
& fuel guage |
|
| Lighting |
Dual 30W Krypton
multireflector headlights & 21/5W brake light |
|
| |
