| Type |
386cc air-/oil-cooled
w/fan, SOHC 4-stroke single |
|
| Bore
x Stroke |
83mm x 71.5mm |
|
| Compression
Ratio |
8.6:1 |
|
| Carburetion |
Mikuni 33mm BSR |
|
| Ignition |
DC-CDI |
|
| Starting
System |
Electric w/auxiliary
pull |
|
| Transmission |
5-speed automatic
clutch w/reverse |
|
|
| Drive
Train |
Yamaha On-Command®
pushbutton; 3-way locking differential; 2WD, 4WD,
locked 4WD; shaft drive |
| |
|
| |
| Suspension/Front |
Independent double
wishbone; 5-way preload adjustment, 5.8-in travel |
|
| Suspension/Rear |
Independent double
wishbone; 5-way preload adjustment, 7.6-in travel |
|
| Brakes/Front |
Dual hydraulic
discs |
|
| Brakes/Rear |
Seaked Wet Brake |
|
| Tires/Front |
AT25x8-12 ITP
Mud Lite |
|
| Tires/Rear |
AT25x10-12 ITP
Mud Lite |
| |
|
| Length |
79.4" |
|
| Width |
43.9" |
|
| Height |
46.7" |
|
| Seat
Height |
35.2" |
|
| Wheelbase |
48.4" |
|
| Turning
Radius |
126" |
|
| Ground
Clearance |
10.5" |
|
| Fuel
Capacity |
4.0 gal. |
|
| Dry Weight |
593 lbs. |
|
| Rack
Capacity |
88 lb front/176
lb rear |
|
| Towing
Capacity |
904 lb. |
| |
|
| Instrumentation |
Speedometer/odometer
& fuel gauge |
|
| Lighting |
Dual 30W Krypton
multireflector headlights & 21/5W brake light |
|
| Color |
Steel Blue; Hunter Green; Red;
Realtree® AP HD™ Camouflage |
