| Type |
660cc liquid-cooled
w/fan, SOHC 4-stroke single; 5-valve |
|
| Bore
x Stroke |
100mm x 84mm |
|
| Compression
Ratio |
9.1:1 |
|
| Carburetion |
Mikuni 42mm BSR |
|
| Ignition |
DC – CDI |
|
| Starting
System |
Electric w/auxiliary
pull |
|
| Transmission |
Yamaha Ultramatic®
V-Belt / H, L, N, R, P |
|
| Engine
Braking |
All Wheel |
|
| Drive
Train |
Yamaha On-Command®
push button 3-way locking differential, 2WD, 4WD,
locked 4WD; Shaft |
| |
|
| |
| Suspension/Front |
Independent double
wishbone, 7.1” travel w/5-way preload adjustment |
|
| Suspension/Rear |
Independent double
wishbone, 9.5” travel w/5-way preload adjustment |
|
| Brakes/Front |
Dual hydraulic
discs |
|
| Brakes/Rear |
Hydraulic disc,
four piston, shaft mounted |
|
| Tires/Front |
AT25 x 8-12 w/aluminum
wheels |
|
| Tires/Rear |
AT25 x 10-12 w/aluminum
wheels |
| |
|
| L x W
x H |
82.1” x
45.3" x 47.6" |
|
| Seat
Height |
34.6” |
|
| Wheelbase |
50.2” |
|
| Turning
Radius |
126” |
|
| Ground
Clearance |
11.8” |
|
| Fuel
Capacity |
5.3 gal. |
|
| Dry Weight |
600 Lb. |
|
| Rack
Capacity |
99 Lb. front
/ 187 Lb. rear |
|
| Towing
Capacity |
1212 Lb. |
| |
|
| Instrumentation |
Digital LCD multi-function
display, speedometer, odometer, dual trip, hour,
clock, fuel, & gear position |
|
| Lighting |
Dual 30W Krypton
multireflector headlights & 21/5W brake light |
|
| DC Outlet |
Standard |
|
| Warranty |
6 Month (Limited
Factory Warranty) |
|
| |
