Type |
401cc liquid-cooled
w/fan, SOHC 4-stroke single |
|
Bore
x Stroke |
84.5mm x 71.5mm |
|
Compression
Ratio |
10.5:1 |
|
Carburetion |
Mikuni 33mm BSR |
|
Ignition |
DC-CDI |
|
Starting
System |
Electric w/auxiliary
pull |
|
Transmission |
Yamaha Ultramatic®
V-belt/F, N, R |
|
Engine
Braking |
Front & rear
wheel |
|
Drive
Train |
Yamaha On-Command®
pushbutton 2WD & 4WD; shaft |
|
|
|
Suspension/Front |
Independent double
wishbone, 6.3" travel w/5-way preload adjustment |
|
Suspension/Rear |
Independent double
wishbone, 7.1" travel w/5-way preload adjustment |
|
Brakes/Front |
Dual hydraulic
discs |
|
Brakes/Rear |
Hydraulic disc |
|
Tires/Front |
AT25x8-12 |
|
Tires/Rear |
AT25x10-12 |
|
|
Length |
78.5" x 43.0"
x 44.1" |
|
Seat
Height |
32.7" |
|
Wheelbase |
48.5" |
|
Turning
Radius |
118" |
|
Ground
Clearance |
10.8" |
|
Fuel
Capacity |
4.0 gal. |
|
Dry Weight |
578 lb. |
|
Rack
Capacity |
88 lb front/176
lb rear |
|
Towing
Capacity |
1102 lb. |
|
|
Instrumentation |
Speedometer, odometer
& fuel guage |
|
Lighting |
Dual 30W Krypton
multireflector headlights & 21/5W brake light |
|
|
