| Type |
230cc air-cooled,
SOHC 4-stroke single |
|
| Bore
x Stroke |
71mm x 58mm |
|
| Compression
Ratio |
8.7:1 |
|
| Carburetion |
Mikuni 33mm BSR |
|
| Ignition |
DC - CDI |
|
| Starting
System |
Electric w/auxiliary
pull |
|
| Transmission |
5-speed automatic
clutch w/reverse |
|
| Engine
Braking |
Rear wheel |
|
| Drive
Train |
2WD; shaft |
| |
|
| |
| Suspension/Front |
MacPherson strut,
4.9" travel |
|
| Suspension/Rear |
Swingarm, 5.3"
travel w/5-way preload adjustment |
|
| Brakes/Front |
Dual hydraulic
discs |
|
| Brakes/Rear |
Fully sealed drum |
|
| Tire/Front |
AT22x7-10 |
|
| Tire/Rear |
AT22x10-10 |
| |
|
| L x W
x H |
75.4" x 40.9"
x 44.0" |
|
| Seat
Height |
30.4" |
|
| Wheelbase |
46.1" |
|
| Turning
Radius |
114" |
|
| Ground
Clearance |
5.9" |
|
| Fuel
Capacity |
3.2 gal. |
|
| Dry Weight |
456 lb. |
|
| Rack
Capacity |
66 lb front/99
lb rear |
|
| Towing
Capacity |
728 lb. |
| |
|
| Instrumentation |
N/A |
|
| Lighting |
Dual 30W Krypton
multireflector headlights & 21/5W brake light |
|
| |
