All-new from the ground up, Raptor
90 has the features to deliver more
fun than ever before, with a new 88cc
SOHC 2-valve engine tuned to develop
excellent low-to-mid rpm range performance.
It also has features surprising in
this class and price range, like a
fully automatic CVT transmission,
dual A-arm front suspension, rear
disc brake, low-profi le tires, and
styling unmistakably inspired by the
mighty Raptor 700R.
Dual A-arm front suspension has
4.4-inches of travel for sporty-riding
comfort, while adding to the Raptor
90’s big-ATV look. Shocks have
5-way preload adjustment to accommodate
a variety of riders and terrain. The
rear swingarm, also 5-way preload
adjustable, offers 3.3-inches of travel.
For sporty looks and handling,
Raptor 90 uses low-profi le Maxxis®
tires. For riding comfort, there are
aggressive-looking full fl oorboards.
For strong, reliable stopping power,
there’s a hydraulic disc brake
with drilled rotor in the back, and
dual sealed drums in the front.
Restricting power output for learning
riders is exceptionally convenient;
there’s a simple plug-in for
the CDI unit.
Available in Team Yamaha Blue/White,
just like full-size ATVs, or in an
exclusive Black/White version with
two graphics choices young riders
will love.
Yamaha
Raptor 90 Mini ATV Engine
The go-getter 88cc 4-stroke SOHC
2-valve engine is tuned to develop
excellent low-to-mid-range performance,
just where it’s needed. Engine
is force-air cooled for performance
and long engine life, and it uses
simple, reliable wet-sump lubrication.
Easy-to-operate electric starting
comes standard, of course, and an
emergency kick starter is also provided
in a storage spot under the seat for
more peace of mind.
Constantly variable transmission
(CVT) means no shifting. Handy for
all riders, it’s a feature entry-level
riders particularly appreciate.
Engine power is transferred to
the rear wheels via a tried-andtrue
chain drive.
The
Yamaha Raptor 90 ATVs don't just come
in blue, they also come in unique color
variations sure to please both boys
and girls
Yamaha
Raptor 90 Mini ATV Chassis/Suspension
Dual A-arm front suspension has
4.4-inches of travel for sportyriding
comfort, while helping to give the
front end the look of a big Raptor.
Shocks have 5-way preload adjustment
to accommodate a variety of riders
and terrain. The rear swingarm, also
5-way preload adjustable, offers 3.3-inches
of travel to enhance riding comfort
and traction.
Raptor 90 is designed to be comfortable
for a wide variety of riders. With
its roomy ergonomics, growing riders
12 and older won’t outgrow the
machine before they’re ready
for more displacement when they’re
older.
Newly designed Maxxis® low-profile
tires, AT18 x 7-8 front and AT18 x
9-8 rear, give Raptor 90 sporty looks
and sporty handling.
For strong, reliable stopping power,
there’s a hydraulic disc brake
in the back with a drilled rotor that’s
protected against rocks and other
obstacles by a beefy guard. Up front,
there are dual sealed drums. There’s
a handlebar-mounted parking brake,
too.
Additional
Features
The DC-CDI digital ignition timing
control system means reliable performance,
with a strong, efficient spark.
Battery and other electrical components
are conveniently and centrally located
for service. Waterproof connectors
add to the overall reliability.
