2014
Polaris Sportsman XP 850 XP
EFI 4x4 ATV Specifications |
| Engine
Type |
4-Stroke
SOHC Twin Cylinder |
| Displacement |
850cc
High Output HO |
| Fuel
System |
Electronic
Fuel Injection |
| Cooling |
Liquid |
| Transmission/Final
Drive |
Automatic
PVT P/R/N/L/H; Sha |
| Drive
System |
On-Demand True AWD/2WD |
Engine Braking System/
Active Descent Control |
Standard/Standard |
| Front
Suspension |
Dual A-Arm 9" (22.9 cm) Travel |
| Rear
Suspension |
Dual A-Arm, Rolled 10.25"
(26 cm) Trave |
| Front/Rear
Brakes |
Single Lever 4-Wheel Hydraulic
Disk with Hydraulic Rear Foot
Brak |
| Parking
Brake |
Park in Transmission/Lockable
Hand Leve |
| Front
Tires |
26 x 8-14; Maxxis |
| Rear
Tires |
26 x 10-14; Maxxis |
| Wheels |
Stamped Steel |
| Wheelbase |
53" (134.6 cm |
| Dry
Weight |
735 lb (345 kg |
Overall Vehicle Size
(L x W x H) |
82.3
x 48.6 x 48.4" (209cm x 123
x 123 cm |
| Ground
Clearance |
11" (28 cm) |
| Seat
Height |
35" (89 cm) |
| Fuel
Capacity |
5.25 gal (19.9 L |
Bed Box Dimensions
(L x W x H) |
N/A |
| Front/Rear
Rack Box Capacity |
25
lb (55 kg)/50 lb (110 kg) |
| Payload
Capacity |
TBD |
| Hitch
Towing Rating |
1,500
lb (680.4 kg) |
| Unbraked
Trailer Towing Capacity |
1,914
lb. |
| Hitch/Type |
Standard/2"
Receiver |
| Cargo
System |
Lock
& Ride |
| Lighting |
Dual
50w High Beam, Dual 50w Low Beam
Headlights; Dual Brakelights/Taillights |
| Electronic Power Steering |
N/A |
| Instrumentation |
Analog
Speedometer, Digital Odometer,
Tachometer, Two Tripmeters, Hour
Meter, Clock, Service Indicator,
Diagnostic Indicator, Gear Indicator,
Fuel Gauge, AWD Indicator, Hi-Temp/Low-Batt
Lights, DC Outlet |
| Colors |
Indy Red, Voodoo Blue LE |
