2011
Polaris RANGER RZR800 EFI UTV / SxS
Specifications |
Engine
Type |
4-Stroke
Twin Cylinder |
Displacement |
760cc
High Output (H.O.) |
Fuel
System |
Electronic
Fuel Injection |
Cooling |
Liquid |
Transmission/Final
Drive |
Automatic
PVT P/R/N/L/H; Shaft |
Drive
System |
On-Demand
True AWD/2WD |
Engine Braking System/
Active Descent Control |
Not
Equipped |
Front
Suspension |
Dual
A-Arm 12" (30.5 cm) Travel |
Rear
Suspension |
Dual
A-Arm, Rolled with Anti-Sway Bar 12"
(30.5 cm) Travel |
Front/Rear
Brakes |
4-Wheel
Hydraulic Disc with Dual-Bore Front
Calipers |
Parking
Brake |
Park
in Transmission |
Front
Tires |
26
x 9-12; ITP 900
XCT |
Rear
Tires |
26
x 11-12; ITP 900
XCT |
Wheels |
Cast
Aluminum |
Wheelbase |
77"
(196 cm) |
Dry
Weight |
1,000
lb (454 kg) |
Overall Vehicle Size
(L x W x H) |
106
x 60 x 70.5"
(269 x 152.4 x 179 cm) |
Ground
Clearance |
12.5"
(32 cm) |
Seat
Height |
N.A. |
Fuel
Capacity |
7.25
gal (27.4 L) |
Bed Box Dimensions
(L x W x H) |
22
x 42 x 6.5"
(56 x 107 x 16.5 cm) |
Front/Rear
Rack Box Capacity |
N.A./300
lb (136.1 kg) |
Payload
Capacity |
740
lb (335.6 kg) |
Hitch
Towing Rating |
1,500
lb (680.4 kg) |
Unbraked
Trailer Towing Capacity |
N.A. |
Hitch/Type |
Standard/1.25"
Receiver |
Cargo
System |
Lock
& Ride |
Lighting |
55W
low/ 60W high |
Electronic Power Steering |
Not
Equipped |
Instrumentation |
Digital
Gauge, Speedometer, Odometer, Tachometer,
Tripmeter, Hour Meter, Clock, Gear Indicator, Fuel Gauge, Hi-Temp/Low-Batt Lights, DC Outlets |
Colors |
Indy
Red |
