2011 Polaris RANGER RZR S 800 EFI UTV / SxS Model Info

NAVIGATION

Introduction | Specifications

2011 Polaris RANGER RZR S 800 UTV / SxS

2011 Polaris Ranger RZR S 800 EFI UTV/SxS - Indy Red & Polaris Ranger RZR 800 Limited Edition Orange Madness

2011 Polaris Ranger RZR S 800 Key Features - New Features!

NEW! Aggressive new front styling that increases airflow by 29%
NEW! Engine Management
System for better driveability and a 30% improvement in range
NEW! In-cab glove box
NEW! Easier-to-use side nets
NEW! ITP 900 XCT Tires
NEW! Two-inch Big Bore Sachs Shocks
800 Polaris H.O. EFI engine
Pure sport machine at 60 inches wide with 12 inches of long-travel suspension and 12.5 inches of ground clearance

Chrome-Moly upper front A-arms for precision and strength
Lowest center of gravity in its class for ground-hugging performance
Independent rear suspension
On-demand, true AWD
Fender flairs and extended rear cab frame supports for sportier look
ROPS Certified Cab
Available in Indy Red
Limited Edition Models include Gloss Black Carbon Fiber/Indy Red and Gloss Black/Orange Madness

2011 Polaris RANGER RZR 800 Limited Edition UTV / SxS

2011 Polaris Ranger RZR 800 Limited Edition Models in Sonic Blue / White & Gloss Carbon Fiber Black / Red

2011 Polaris RANGER RZR800 EFI UTV / SxS Specifications
Engine Type	4-Stroke Twin Cylinder
Displacement	760cc High Output (H.O.)
Fuel System	Electronic Fuel Injection
Cooling	Liquid
Transmission/Final Drive	Automatic PVT P/R/N/L/H; Shaft
Drive System	On-Demand True AWD/2WD
Engine Braking System/ Active Descent Control	Not Equipped
Front Suspension	Dual A-Arm 12" (30.5 cm) Travel
Rear Suspension	Dual A-Arm, Rolled with Anti-Sway Bar 12" (30.5 cm) Travel
Front/Rear Brakes	4-Wheel Hydraulic Disc with Dual-Bore Front Calipers
Parking Brake	Park in Transmission
Front Tires	26 x 9-12; ITP 900 XCT
Rear Tires	26 x 11-12; ITP 900 XCT
Wheels	Cast Aluminum
Wheelbase	77" (196 cm)
Dry Weight	1,000 lb (454 kg)
Overall Vehicle Size (L x W x H)	106 x 60 x 70.5" (269 x 152.4 x 179 cm)
Ground Clearance	12.5" (32 cm)
Seat Height	N.A.
Fuel Capacity	7.25 gal (27.4 L)
Bed Box Dimensions (L x W x H)	22 x 42 x 6.5" (56 x 107 x 16.5 cm)
Front/Rear Rack Box Capacity	N.A./300 lb (136.1 kg)
Payload Capacity	740 lb (335.6 kg)
Hitch Towing Rating	1,500 lb (680.4 kg)
Unbraked Trailer Towing Capacity	N.A.
Hitch/Type	Standard/1.25" Receiver
Cargo System	Lock & Ride
Lighting	55W low/ 60W high
Electronic Power Steering	Not Equipped
Instrumentation	Digital Gauge, Speedometer, Odometer, Tachometer, Tripmeter, Hour Meter, Clock, Gear Indicator, Fuel Gauge, Hi-Temp/Low-Batt Lights, DC Outlets
Colors	Indy Red
