| Engine |
Liquid-cooled, 90-degree,
four-stroke V-twin
SOHC, four valves per cylinder |
|
| |
| |
| |
| Carburetion |
(2) Keihin CVKR-34 |
|
| Starting |
Electric / Digital DC-CDI |
|
| Transmission |
Continuously variable
belt-drive transmission with high and
low range, plus reverse, and Kawasaki
Engine Brake Control |
|
| Final drive |
Selectable four-wheel
drive with Variable Front Differential
Control, shaft |
|
| Frame type |
Large diameter, thin-walled,
high-tensile tubular steel |
|
| Front suspension /
wheel travel |
Adjustable dual A-arm
with gas charged shocks / 7.5 in. |
|
| Rear suspension / wheel
travel |
Adjustable Independent
Rear Suspension (IRS) with gas charged,
reservoir shocks / 7.3 in. |
|
| Front tires |
Maxxis 26x8-12 |
|
| Rear tires |
Maxxis 26x10-12 |
|
| Front brakes |
Dual hydraulic discs with
2-piston calipers |
|
| Rear brake |
Sealed, oil-bathed, multi-disc |
|
| |
| |
| |
| |
| Ground clearance |
11.2 in. |
|
| Lighting |
(2) 40W headlights, (2)
TK W taillight, TKW stoplight |
|
| Cargo bed capacity |
500 lbs, 44.1 W x 32.7
L x 12 in. H |
|
| Towing capacity |
1,300 lbs. |
|
| |
| |
| Instruments |
R/N/P/4WD indicators,
water temp and oil pressure lamps, digital
meter (LE only) |
|
| Standard Colors |
Sunbeam Red, Woodsman
Green, REALTREE™ Hardwoods Green®
HD |
|
| |
| |
