Engine:
Air-cooled, four-stroke, single cylinder
Displacement: 49.5cc
Bore x stroke: 39.0 x 41.4mm
Compression ratio: 10.0:1
Carburetion: Keihin PTE 16
Ignition: Solid state CDI
Transmission: Continuously Variable
Automatic
Final drive: Chain
Frame: Double cradle, steel
Suspension front / wheel travel: Single
A-arm with twin shock absorbers / 2.8 in.
Suspension rear / wheel travel:
Swingarm with single shock absorber / 2.9 in.
Front tire: AT16x8-7 tubeless
Rear tire: AT16x8-7 tubeless
Front brakes / rear brake: Dual
mechanical drums / Hydraulic disc
Overall length: 55.1 in.
Overall width: 34.7 in.
Wheelbase: 38.0 in.
Ground clearance: Center of chassis
– 5.3 in.
Track Front/Rear: 27.2 / 27.6 in.
Fuel capacity: 1.5 gal.
Dry weight: 232 lbs.
MSRP: $1,749
Color choices: Lime Green, White
|
