| Model:
|
TRX420TE
(with ESP) / TRX420TM |
| Engine
Type: |
420cc
liquid-cooled fuel-injected
OHV wet-sump longitudinally
mounted single-cylinder
four-stroke |
| Bore
and Stroke: |
86.5mm
x 71.5mm |
| Compression:
|
8.5:1 |
| Carburation: |
36mm
constant-velocity |
| Induction:
|
Keihin
34mm throttle-body fuel-injection
system |
| Ignition:
|
Full
transistor with electronic
advance |
| Starter:
|
Electric
with optional auxiliary
recoil |
| Clutch:
|
Automatic |
| Transmission
|
TRX420TE:
ESP five-speed with Reverse
TRX420TM: Five-speed with
Reverse |
| Driveline:
|
Direct
rear driveshaft |
| Suspension |
Front:
Independent double-wishbone;
6.3 inches travel
Rear: Swingarm with single
shock; 6.3 inches travel |
| Brakes |
Front:
Dual hydraulic disc
Rear: Sealed mechanical
drum |
| Tires |
Front:
24x8-12
Rear: 24x10-11 |
| Length:
|
80.9
inches |
| Width:
|
46.1
inches |
| Height:
|
45.2
inches |
| Seat
Height: |
32.4
inches |
| Ground
Clearance: |
6.5 inches |
| Wheelbase:
|
49.4
inches |
| Turning
Radius: |
8.9 feet |
| Curb
Weight** |
TRX420TE:
549 pounds
TRX420TM: 547 pounds |
| Fuel
Capacity: |
3.6 gallons
(including 1.0 gallon
reserve) |
| Colors:
|
Red,
Olive, Yellow |
| **Includes
all standard equipment,
required fluids and a
full tank of fuel-ready
to ride. |
| Recommended
for riders 16 years of
age and older. |
