| Model: |
TRX500TM |
| Engine
Type: |
475cc air-cooled
OHV longitudinally mounted single-cylinder
four-stroke |
| Bore
and Stroke: |
92mm x 71.5mm |
Carburetion: |
36mm constant-velocity |
| Ignition: |
CD with electronic
advance |
| Starter: |
Electric with
auxiliary recoil |
| Clutch: |
Automatic |
| Transmission: |
Five-speed
with Reverse |
| Driveline: |
Direct rear
driveshaft |
Suspension:
|
Front: Independent
double-wishbone; 6.7 inches
travel
Rear: Swingarm with dual shocks;
6.7 inches travel |
Brakes:
|
Front: Dual
hydraulic 180mm disc
Rear: Sealed 180mm mechanical
drum
Tires |
Front:
|
25 x 8-12 |
| Rear: |
25 x 10-12 |
| Length: |
83 inches |
| Width:
|
46.8 inches |
| Height: |
46.0 inches |
| Seat
Height: |
33.9 inches |
| Ground
Clearance: |
7.5 inches |
| Wheelbase:
|
50.9 inches |
| Turning
Radius: |
9.8 feet |
| Dry
Weight: |
554 pounds |
| Fuel
Capacity: |
4.2 gallons,
including 0.9-gallon reserve |
| Colors: |
Olive, Yellow,
Red |
| For
riders 16 years of age and older. |
