CVT,
sub-transmission with high,
low, park, neutral & reverse,
Standard Engine braking
Drive
Train
Selectable
2w/4w shaft driven with Visco-lok†
front differential
CHASSIS
Frame
SST
G2
Front
Suspension Type
Double
A-arm
Travel
9
in (229 mm)
Rear
Suspension Type
TTI
independent
Travel
9.3
in (236 mm)
Front
Brake
Dual
214mm Ventilated discs with
hydraulic twin-piston calipers
Rear
Brake
Dual
214mm Ventilated discs with
hydraulic twin-piston calipers
Tires
/Front
ITP
Holeshot 25 x 8 x 12 in (635
x 203 x 305 mm)
Tires
/Rear
ITP
Holeshot 25 x 10 x 12 in (635
x 254 x 305 mm)
Wheels
12"
cast-aluminum wheels
DIMENSIONS
L
x W x H
86
x 46 x 45 in
(2,184 x 1,168 x 1,143 mm )
Wheelbase
51
in (1,295 mm)
Dry
Weight
687
lbs (339 kg)
Ground
Clearance
12
in (305 mm)
Seat
Height
34.5
in (877 mm)
Towing
Capacity
1,300
lbs (590 kg)
Fuel
Capacity
5.4
US gal (20.5L)
FEATURES
Instrumentation
Multi-function digital LCD gauge: Speedometer, tachometer (bar
graph RPM, bottom bar numerical
RPM), odometer, trip & hour
meters, diagnostic center, gear
position, engine hour meter,
4x4 indicator, temperature and
engine lights, fuel gauge, auto
shut off after 15 minutes
