CVT,
sub-transmission with high,
low, park, neutral & reverse,
Standard Engine braking
Drive
Train
Selectable
2w/4w shaft driven with Visco-lok†
front differential
CHASSIS
Frame
SST
Front
Suspension Type
Double
A-arm,
Travel
8
in (203 mm)
Rear
Suspension Type
TTI
independent
Travel
9
in (229 mm)
Front
Brake
2
inboard hydraulic discs
Rear
Brake
1
inboard hydraulic disc
Tires
/Front
26
x 8 x 12 in (660 x 203 x 305
mm)
Tires
/Rear
26
x 10 x 12 in (660 x 254 x
305 mm)
Wheels
12"
cast-aluminum wheels
DIMENSIONS
L
x W x H
86
x 46 x 45 in
(2,184 x 1,168 x 1,143 mm )
94
x 46 x 45 in
(2,387 x 1,168 x 1,143 mm)
Wheelbase
51
in (1,295 mm)
59
in (1,499 mm)
Dry
Weight
669
lbs (303 kg)
719
lbs (326 kg)
Ground
Clearance
12
in (305 mm)
12
in (305 mm)
Seat
Height
34.5
in (877 mm)
34.5
in (877 mm)
Rack
Capacity
Front:
100 lbs (45 kg)
Rear: 200 lbs (90 kg)
Front:
100 lbs (45 kg)
Rear: 200 lbs (90 kg)
Towing
Capacity
1,300
lbs (590 kg)
1,300
lbs (590 kg)
Fuel
Capacity
4.3
US gal (16.3L)
4.3
US gal (16.3L)
Rear
Storage
5.3
US gal (20L)
Rear
storage 5.3 US gal (20L)
CRS (Convertible Rack System)
FEATURES
Instrumentation
Multi-function digital LCD
gauge: Speedometer,
tachometer (bar graph RPM,
bottom bar numerical RPM),
odometer, trip & hour
meters, diagnostic center,
gear position, engine hour
meter, 4x4 indicator, temperature
and engine lights, fuel gauge,
auto shut off after 15 minutes
