CVT,
sub-transmission with high,
low, park, neutral &
reverse, Standard Engine
braking
Drive
Train
Selectable
2w/4w shaft driven with
Visco-lok† front differential
CHASSIS
Frame
SST
Front
Suspension Type
MacPherson
Travel
7
in (178 mm)
Rear
Suspension Type
TTI
independent
Travel
8
in (203 mm)
Front
Brake
2
inboard hydraulic discs
Rear
Brake
1
inboard hydraulic disc
Tires
/Front
25
x 8 x 12 in
Tires
/Rear
25
x 11 x 12 in
Wheels
Steel
DIMENSIONS
L
x W x H
86
x 46 x 45 in
(2,184 x 1,168 x 1,143 mm
)
94
x 46 x 45 in
(2,387 x 1,168 x 1,143 mm)
Wheelbase
49
in (1,244 mm)
57
in (1,447 mm)
Dry
Weight
630
lbs (296 kg)
680
lbs (308kg)
Ground
Clearance
9.3
in (236 mm)
9.3
in (236 mm)
Seat
Height
35
in (889 mm)
35
in (889 mm)
Rack
Capacity
Front:
100 lbs (45 kg)
Rear: 200 lbs (90 kg)
Front:
100 lbs (45 kg)
Rear: 200 lbs (90 kg)
Towing
Capacity
1,300
lbs (590 kg)
1,300
lbs (590 kg)
Fuel
Capacity
4.3
US gal (16.3L)
4.3
US gal (16.3L)
Rear
Storage
5.3
US gal (20L)
Rear
storage 5.3 US gal (20L)
CRS (Convertible Rack System)
FEATURES
Instrumentation
Multi-function digital LCD
gauge: Speedometer,
tachometer (bar graph RPM,
bottom bar numerical RPM),
odometer, trip & hour
meters, diagnostic center,
gear position, engine hour
meter, 4x4 indicator, temperature
and engine lights, fuel
gauge, auto shut off after
15 minutes
