ENGINE |
OUTLANDER
800 R EFI 4X4
|
OUTLANDER
MAX 800 R EFI 4X4
|
| Type |
799.9cc,
V-twin, liquid-cooled, SOHC, 8-valve
(4-valve / cyl) |
799.9cc,
V-twin, liquid-cooled, SOHC, 8-valve
(4-valve / cyl) |
| Bore
& Stroke |
91
x 62 mm |
91
x 62 mm |
| Fuel
Delivery |
EFI,
46mm Throttle Body,
2 Siemens‡ VDO injectors |
EFI,
46mm Throttle Body,
2 Siemens‡ VDO injectors |
| Starting
System |
Electric |
Electric |
| Transmission |
CVT,
sub-transmission with high, low,
park, neutral & reverse, Standard
Engine braking |
CVT,
sub-transmission with high, low,
park, neutral & reverse, Standard
Engine braking |
| Drive
Train |
Selectable
2w/4w shaft driven with Visco-lok†
front differential |
Selectable
2w/4w shaft driven with Visco-lok†
front differential |
CHASSIS |
Frame
|
SST |
SST |
| Front
Suspension Type |
Double
A-arm,
Forged Aluminum upper arm |
Double
A-arm,
Forged Aluminum upper arm |
| Travel |
8
in (203 mm) |
8
in (203 mm) |
| Rear
Suspension Type |
TTI
independent |
TTI
independent |
| Travel |
9
in (229 mm) |
9
in (229 mm) |
| Front
Brake |
2
inboard hydraulic discs |
2
inboard hydraulic discs |
| Rear
Brake |
1
inboard hydraulic disc |
1
inboard hydraulic disc |
| Tires
/Front |
26
x 8 x 12 in (660 x 203 x 305 mm) |
26
x 8 x 12 in (660 x 203 x 305 mm) |
| Tires
/Rear |
26
x 10 x 12 in (660 x 254 x 305
mm) |
26
x 10 x 12 in (660 x 254 x 305
mm) |
| Wheels |
Steel |
Steel |
DIMENSIONS |
| L
x W x H |
86
x 46 x 45 in
(2,184 x 1,168 x 1,143 mm ) |
94
x 46 x 45 in
(2,387 x 1,168 x 1,143 mm) |
Wheelbase
|
51
in (1,295 mm) |
59
in (1,499 mm) |
| Dry
Weight |
663
lbs (290 kg) |
713
lbs (313 kg) |
| Ground
Clearance |
12
in (305 mm) |
12
in (305 mm) |
Seat
Height
|
34.5
in (877 mm) |
34.5
in (877 mm) |
| Rack
Capacity |
Front:
100 lbs (45 kg)
Rear: 200 lbs (90 kg) |
Front:
100 lbs (45 kg)
Rear: 200 lbs (90 kg) |
| Towing
Capacity |
1,300
lbs (590 kg) |
1,300
lbs (590 kg) |
| Fuel
Capacity |
5.3
US gal (20L) |
5.3
US gal (20L) |
FEATURES |
| Instrumentation |
Speedometer,
tachometer (bar graph RPM, bottom
bar numerical RPM), odometer,
trip meter, diagnostic center,
gear position, hour meter, engine
hour meter, 4x4 indicator, temperature
and engine lights, fuel gauge,
auto shut off after 15 minutes |
Speedometer,
tachometer (bar graph RPM, bottom
bar numerical RPM), odometer,
trip meter, diagnostic center,
gear position, hour meter, engine
hour meter, 4x4 indicator, temperature
and engine lights, fuel gauge,
auto shut off after 15 minutes |
| Anti-theft |
D.E.S.S.
(digital encoded security system) |
D.E.S.S.
(digital encoded security system) |
| Storage |
Rear
storage 5.3 US gal (20L) |
Rear
storage 5.3 US gal (20L)
CRS (Convertible Rack System) |
| Electrical |
Prewired
for winch |
Prewired
for winch |
| Lighting |
2
fender mounted headlamps
(35W) with tail light / brake
light |
2
fender mounted headlamps
(35W) with tail light / brake
light |
| DC
Outlet |
Lighter-type
in console, Standard connector
at the back (15A) |
Lighter-type
in console, Standard connector
at the back (15A) |
| Package
Available |
XT
Package (Also
Availiable for Max)
BRP XL 3000 winch with roller
fairlead and wired remote controls
Cast aluminum rims (except camo)
Agressive Carlisle ACT Radial
tires
Heavy-duty front & rear bumpers
Handlebar wind deflectors |
Ltd
package:
BRP
XL3000 winch with roller fairlead
and wired remote controls, Integrated/
removable Garmin Quest GPS, Radiant
Red metallic paint, Exclusive
Ltd 6-spoke cast aluminum wheels,
Agressive Carlisle ACT radial
tires, New heavy-duty front &
rear bumpers, Mudguards, Handlebar
wind deflectors, Premium 2-tone
seat,
Comfort grips, Chrome muffler
trim, New front fascia |
| XT
Package Colors |
Black,
Viper Red, Yellow, Camo |
Radiant
Red Metallic Paint |
| Standard
Colors |
Yellow,
Viper Red |
Yellow,
Viper Red |
