The
650 H1 has carved a niche in the 650 class as
a torque monster that loves to play. Oh yeah,
if you need to pull your house across the yard,
it can do that too!
The H1 is a single-cylinder,
liquid-cooled 641cc four-stroke engine designed
by Arctic Cat for massive low-end and mid-range
torque. The automatic transmission will take
riders through or over just about anything without
so much as a whimper. The 650 H1’s are
loaded for any work or play you demand of them.
The plastic bodywork calls attention
to the H1 with extra-wide fenders to protect
the rider from mud and water spray, “cat-eye”
headlights add style and excellent illumination,
and integrated full-length plastic floorboards
enhance sure-footed traction. The seat is wider
for increased comfort, and the seat latch allows
quick removal and access to a handy tool tray.
Handling the power and torque
of the H1 is an equally capable chassis that
includes a double A-arm fully independent rear
suspension (FIS) and double A-arm front, with
preload adjustable shocks and 10-inches of suspension
travel. Ground clearance is a best-in-class
12-inches which, coupled with a full-length
high-density plastic skid plate, gives riders
the confidence to clear large obstacles without
damaging the frame.
Complementing the all-powerful
goodies on this machine are features designed
for comfort and convenience. SpeedRacks offer
dozens of accessory attachment options. Going
from 2WD to 4WD is as simple as pressing an
electronic shift button, while activating the
full-lock front differential requires only a
flip of a handlebar-mounted lever. A 2-in. “automotive
style” receiver hitch, long-range 6.5-gallon
fuel tank, digital instrument pod (MPH, odometer,
dual trip meters, hour meter, clock and fuel
level) and Start-In-Gear capability complete
the package.
Consumers that want to stand
out from the rest of the crowd can opt for the
flashy LE which come complete with machined
aluminum wheels, a one-piece front brush guard
and rear accessory bumper, a 2,500-lb. Warn
winch and is available in Dark Green.
An Arctic Cat produced engine
in their state-of-the-art manufacturing facility
New 36mm CVK carburetor
with automatic choke helps to reduce emissions
Liquid cooling system with
high-capacity radiator and thermostatically-controlled
cooling fan provides consistent engine operating
temperatures
Duramatic Automatic Transmission
with long life maintenance-free belt
650
H1 4x4 Chassis/Suspension Info
All LE models have machined
aluminum wheels, one-piece front brush guard,
rear accessory bumper and a 2500lb. Warn Winch.
650 H1 LE is available in Dark Green.
Displays up to 14 critical
operation information indicators including:
clock/hour meter, fuel level, mode button,
set/reset button, odometer/trip, gear position,
speedometer/tachometer, needle display, differential
lock, drive select, high beam, battery condition,
temperature and oil pressure. (LE model also
has Analog Speedometer readout)
The newly developed Goodyear
Rawhide RS is standard on all Arctic Cat ATVs
(25x8-12 front, 25x10-12 rear) for improved
traction, durability and ride handling.
A redesigned handlebar with
improved bend for increased ergonomic comfort
in all riding situations.
Easily removable engine
covers protect riders legs from engine heat
dissipation while diffusing sound, creating
a clean appearance to the engine compartment.
With Hi/Lo-Range allows responsive
acceleration and engine braking. Transmission
also features start-in-gear to get you going
faster.
Wide fenders for increased
water and mud protection, a high-density durable
plastic skid plate that doesn’t rip
or rust, “Stick Stoppers” protect
CV boots and ATVs are outfitted with Zero-maintenance
suspension bushings, sealed drive shafts (front
and rear), and constant-velocity (CV) joints
Arctic Cat ATVs have an optional
sway bar available as an accessory purchase
through your authorized dealer. Similar to
any off-road 4x4 vehicle, eliminating the
sway bar, lets the 10” of front or rear
Fully Independent Suspension articulate through
the full range of suspension travel. This
increased articulation provides full tire
contact in all types of off-camber terrain.
The addition of the sway bar will impact the
traction capabilities; however, it will enhance
flatter cornering in aggressive trail riding
12.0” of ground clearance
enhances the ability to navigate through mud
or over large rocks, logs, and other objects
encountered in rough terrain
Industry leading weight capacity
and overall cargo carrying surface area allows
100 lb carrying capacity on the front rack
and 200 lbs. on the rear
Allows very quick installation
and removal of a wide variety of Arctic Cat
exclusive accessories without the need for
tools, bloody knuckles or swearing
SpeedRack and its accessories
add value to the machine and also enhance
the efficiency of your hunting, fishing, farming
or utility chores
This feature allows the
consumer to remove the hitch from their 2”
automotive receiver and install it into the
ATV’s receiver hitch
Low maintenance, positive
stopping power in either dry or wet conditions
Set the spring preload (5
rear positions, 5 front positions) on the
shocks to tailor the ride to individual riding
styles, terrains and loads
Full-lock front differential
transfers engine torque to both front wheels
when selected for added traction with a flip
of the switch. 4x4/2x4 switch is located on
right-side handlebar for quick, convenient
shifting in-and-out of four-wheel drive
650
H1 4x4 Key Features
Fully Independent Suspension
Adjustable preload shocks
12.0 inches of industry
leading ground clearance
10 inches of front and rear
suspension travel
SpeedRacks are standard
Fully automatic transmission
Reliable 4-Stroke engine
On-the-fly electric shift
2-to 4-wheel drive with front locking differential
Digital gauges with 14 different
display indicators
