Automatic CVT with EBS, Hi/Lo Range, Reverse & Park
Drive System
2/4 WD + Electric Diff Lock
Overall
Width
47.5/120.6
Overall
Height
50.3/127.8
Overall
Length
98.6/250.4
Wheel Base
58/147.3
Suspension
Travel Front
10/25.4
Suspension
Travel Rear
10/25.4
Ground Clearance
11/27.9
Suspension
Type - Front
Double A-Arm
Suspension
Type - Rear
Double A-Arm
Front Brakes
Hydraulic Disc
Rear Brakes
Hydraulic Disc
Tire Front
25x8-12
Tire Rear
25x10-12
Max Fuel
Capacity
5.3/20.1
Front Rack Capacity
100/45.4
Rack/Box Capacity
50/22.7
Towing Capacity
1050/476.3
Alternator
Capacity
28 Amps
Speedometer
Digital
Odometer
Digital
Dry Weight (lbs)
764/346.5
Available Colors
Desert Red Metallic Paint
Special Features
Power Steering, Aluminum Wheels, Automotive-Style Paint, Sway Bar, Park, Front SpeedRack, Rear 2" Receiver, Duro 3 Star Kaden Tires
