2009 Arctic Cat Prowler XT
650 H1 UTV - Continued
Prowler
XT 650 H1Side
X Side Engine:
|
- Engine - 641cc,
SOHC 4-stroke, 4-valve, single-cylinder,
liquid cooled engine
- Arctic Cat-Built
- An Arctic Cat produced performance-based
engine built in their state-of-the-art
St. Cloud manufacturing facility
- Carburetor -
36mm CVK carburetor with automatic choke
for easy starting
- Cooling -
Liquid cooling system with high-capacity
radiator and thermostatically-controlled
cooling fan provides consistent engine
operating temperatures
- Transmission
- Duramatic Automatic Transmission
with Hi/Lo-Range allows responsive acceleration
and engine braking. Transmission also
features
start-in-gear to get you going faster
with long life maintenance-free belt
- Air Intake -
Quarter wave intake tuner cancels out
unwanted sounds reducing air intake decibels
6db to the riders ear.
- Rigid Airbox
- Also reduces sound along with
exhaust and muffler – also increases
low end torque. The muffler has a longer
head pipe and longer/larger diameter mild
steel muffler.
- Clutch Ducts
- Clutch air intake has increased
cooling and flow
|
Prowler
XT
650 H1
Side-X-Side Chassis/Suspension:
|
-
 |
Arctic
Cat XT 650 H1 Side X Side
|
Cockpit
- Dual
bucket seats with center console allow
you easy access to the conveniently located
dual plug 12V accessory outlets in the
dashboard, glovebox with storage door,
or molded tool kit, located underneath
the passenger seat. Prowler floors sit
higher to protect riders feet from the
elements when forging water crossings
or muddy terrain
- Easier Driver/Passenger
Entry/Departure - The armrests,
or side canopy supports, received a larger
radius for ease of entry and departure
of vehicle, while new seat belts have
larger button for easier passenger and
driver removal
- Plastic Fascia
Bumper - The XT shares the same
bumper and plastic fascia design with
the XTX for enhanced styling.
- Easier Driver/Passenger
Entry/Departure - The armrests,
or side canopy supports have a large radius
for ease of entry and departure of vehicle,
while the seat belts have large button
for easier passenger and driver removal
- Suspension -
Similar to all Arctic Cat ATVs, the Prowler
leads the way with 12.5” of ground
clearance and 10” of suspension
travel front and rear to clear the gnarliest
of obstacles
- Frame Protection
- Frame cover underneath running
board/entry areas – Helps styling
and aids in frame protection as well as
keep mud and debris from entering and
collecting on skidplates
- Brakes -
Foot operated front and rear disk brakes
provide positive stopping power, and also
has a foot operated mechanical parking
brake
- Large Storage
and Hauling Capacities - A fully
composite rear cargo box has a 600lb.
hauling capacity, resists rust, denting
and also acts as a dump box with a pull
of a lever located behind the driver seat.
A large under hood storage compartment
can hold 25 lbs. of gear or doubles as
a cooler that holds ice. A dash mounted
glovebox with door, provides additional
storage. The Prowler is rated for a 1500lb
towing capacity and also has a single
hand-operated tailgate latch like a pickup
truck for easy bed access
- Rims and Tires
- Cast aluminum 14” wheels
are standard with 26x9R14 Goodyear MTR
front tires with 26x11R14 Goodyear MTR’s
in the rear provide superb traction in
all conditions
- Digital/Analog
Gauges - Displays 14 critical
operation indicators including: MPH, RPM,
odometer, dual trip, hours, clock, fuel
level and gear position, also has red
display for nighttime readability
- 4WD Controls
with Diff Lock - The Prowler
cockpit is laid out so that everything
is at your fingertips. 2-wheel to 4-wheel
drive is electrically selectable with
a full locking front differential that
is manually operated. A reverse override
button is located on the center console
for added wheel speeds when needed. A
rack and pinion steering system provides
easy turning in 2- and 4-wheel drive applications
- 2-Inch Automotive
Style Receiver Hitch - This feature
allows the consumer to remove the hitch
from their 2” automotive receiver
and install it into the Prowler’s
receiver hitch located on the front and
the rear of the vehicle
- Tool Kit -
Conveniently molded into the passenger
side seat for easy access and secure fit
|
Additional
Prowler XT
650 H1
UTV Features:
|
- Color Options
- Green, Red, Lime
|
